Запчасти Case 880C (028) - INTAKE MANIFOLD, 504BD DIESEL ENGINE (01) - ENGINE

1

A154446

MANIFOLD

ASSEMBLY - intake, Includes: Ref. 2 - 4

1шт.

2

L10283

PLUG

- heater

1шт.

3

A20916

MANIFOLD GASKET

GASKET - plug

1шт.

4

221-1849

PLUG

- square head, 1/8 inch PT

1шт.

6

A59077

STUD

- manifold to head, 3/8 NC x 1-13/16 inch

12шт.

7

195-25

WASHER,3/8"

- flat, 13/32 x 13/16 x 1/16 inch (10 x 21 x 2)

12шт.

8

92-6

LOCK WASHER,3/8"

16шт.

9

25-166

NUT,3/8"-16, G5, Hvy

- hex, 3/8 inch NC

12шт.

10

A58662

MANIFOLD GASKET

-, Serial Range: manifold-head

6шт.

11

A60458

ELBOW

- air intake

1шт.

12

A58910

GASKET

-, Serial Range: elbow-manifold

1шт.

13

13-624

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

- hex, 3/8 NC x 1-1/2 inch

4шт.

14

25-106

NUT,3/8"-16, G5

- hex, 3/8 inch NC

4шт.

15

A64966

MANIFOLD

- exhaust, front

1шт.

16

A58664

MANIFOLD

- exhaust, rear

1шт.

17

A58666

MANIFOLD GASKET

- manifold to head, exhaust

6шт.

18

A59077

STUD

- manifold to head, 3/8 NC x 1-13/16 inch, exhaust

12шт.

19

92-6

LOCK WASHER,3/8"

exhaust manifold 3/8"

12шт.

20

131-903

NUT,3/8"-16

NUT - hex, 3/8 inch NC Seezpruf, exhaust manifold

12шт.
