Запчасти Case 880C (088) - INSTRUMENT PANELS, PIN 6205236 AND AFTER (06) - ELECTRICAL SYSTEMS

1

321-6098

PANEL

- instrument, left-hand

1шт.

2

S956214

COVER

- left-hand console, black color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

2

S956663

COVER

- left-hand console, brown color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

3

321-6097

PANEL

- instrument, right-hand

1шт.

4

S956255

COVER

- right-hand console, black color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

4

S956661

COVER

- right-hand console, brown color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

5

S615715

BOOT

- control lever

2шт.

6

S239340

FLANGE

- boot retaining

2шт.

7

179-156

SCREW,Cross Oval Hd, #10 - 24 x 3/4"

MACHINE SCREW - No. 10 - 24 NC x 3/4"

27-28шт.

8

F64315

WASHER

- special finishing, No. 10

13-14шт.

9

S117167

CLIP

NUT - U-type, No. 10 - 24 NC

23-24шт.

10

86632551

NUT,#10-24, GB

NUT, LOCK, #10-24, GB

4шт.

11

S118869

BAR

- right-hand, Serial Range: cover-console

1шт.

12

S956245

PANEL

CONSOLE - left-hand, outside, black color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

12

S956664

PANEL

CONSOLE - left-hand, outside, brown color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

13

S956238

PANEL

CONSOLE - left-hand, inside, black color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

13

S956665

PANEL

CONSOLE - left-hand, inside, brown color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

14

S956254

PANEL, SIDE

CONSOLE - right-hand, black color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

14

S956662

PANEL, SIDE

CONSOLE - right-hand, brown color

1шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

15

S514717

COVER

- access, right-hand console, black color

2шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

15

S516014

COVER

- access, right-hand console, brown color

2шт.

Black color parts are used on PIN 6205236-6205557. Brown color parts are used on PIN 6205558 and after.

1шт.

16

S239381

BRACKET

- console support, rear

2шт.

17

S514941

BRACKET

- console support, right-hand front

1шт.

18

179-156

SCREW,Cross Oval Hd, #10 - 24 x 3/4"

MACHINE SCREW - No. 10 - 24 NC x 3/4"

8шт.

19

S117167

CLIP

NUT - U-type, No. 10 - 24 NC

8шт.

20

187-575

SELF-TAP SCREW,Hex Washer, 1/4" - 20 x 3/4"

BOLT - hex head, 1/4" - 20 NC x 3/4"

16шт.

21

195-2250

WASHER,.266" x 13/16" x .083"

- flat, 1/4"

6шт.

22

196-5

WASHER,13/32" x 1 1/16" x .095", HDN

- flat, 3/8"

2шт.

23

131-52

NUT,3/8"-16, GC

NUT - hex, 3/8" - 16 NC

2шт.

24

353-404

PLUG,Dome, .500" hole, Nylon

(13 mm), Used to plug rear switch hole in LH instrument panel and when optional work lamp or windshield washer switches are not used Dome, .500" hole, Nylon

1-3шт.

25

353-407

PLUG,Dome, .687" hole, Nylon

- 11/16" (18 mm) diameter, used to plug rear warning lamp hole in right-hand instrument panel and when optional cold start switch is not used

1-2шт.

26

353-402

PLUG,Dome, .375" hole, Nylon

(10 mm), Used to plug hole in instrument panel when circuit breaker for optional work lamps is not used Dome, .375" hole, Nylon

1шт.

27

113-4

BOLT,Hex, 1/4" - 20 x 1", Gr 5

2шт.

28

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

2шт.

29

195-2251

WASHER,.281" x 1" x .109"

- flat, 1/4"

2шт.
