Запчасти Case 880B (008) - MANIFOLDS, 336BDT DIESEL ENGINE, INTAKE MANIFOLD (01) - ENGINE

1

A154149

MANIFOLD

- intake (Replaces A140120)

1шт.

2

221-1849

PLUG

- 1/8" PT hex socket head

1шт.

3

A58662

MANIFOLD GASKET

- intake manifold

4шт.

4

A20917

PLUG

- manifold (Heater hole)

1шт.

5

A20916

MANIFOLD GASKET

GASKET - plug

1шт.

6

A59077

STUD

- 3/8" NC x 1-3/4"

8шт.

7

92-6

LOCK WASHER,3/8"

8шт.

8

195-25

WASHER,3/8"

- 13/32" x 13/16" x 5/64" (10.32 x 20.64 x 1.98 MM)

8шт.

9

25-166

NUT,3/8"-16, G5, Hvy

- 3/8" NC hex

8шт.

10

41-1042

PLUG,Cup, 2 5/8"

- 2-3/8" cup type (60.33 MM)

1шт.

15

A61001

MANIFOLD

- exhaust

1шт.

16

A58895

GASKET

- exhaust manifold

4шт.

17

A59077

STUD

- 3/8" NC x 1-3/4", exhaust manifold

8шт.

18

92-6

LOCK WASHER,3/8"

exhaust manifold 3/8"

8шт.

19

131-903

NUT,3/8"-16

NUT - 3/8" NC hex (Seez-Pruf), exhaust manifold

8шт.
