Запчасти Case 880 (006) - MANIFOLDS, 336BDT DIESEL ENGINE, INTAKE MANIFOLD (01) - ENGINE

1

A140120

MANIFOLD

- intake (Used with A153249 engine) (1st used engine serial no. 10151851)

1шт.

2

A20917

PLUG

- heater hole (Use with A140120 manifold)

1шт.

3

A20916

MANIFOLD GASKET

GASKET - heater hole plug

1шт.

4

A154149

MANIFOLD

- intake (Used with A66369 engine) (Used prior to engine serial no. 10151851) (Replaces A59225) (Replaces A152825)

1шт.

5

221-1011

DRAIN PLUG,Sq Hd, 1/8"-27 NPTF

PLUG - 1/8" PT, square head (1 used with A140120 manifold and 2 used with A152825 manifold)

1шт.

6

41-1042

PLUG,Cup, 2 5/8"

- 1-3/8" cup type

1шт.

7

A58662

MANIFOLD GASKET

- intake manifold

4шт.

8

A59077

STUD

- 3/8" NC x 1-3/4"

8шт.

9

195-25

WASHER,3/8"

- 3/8 x 13/16 x 1/16"

8шт.

10

92-6

LOCK WASHER,3/8"

8шт.

11

25-166

NUT,3/8"-16, G5, Hvy

- 3/8" NC hex

8шт.

15

A61001

MANIFOLD

- exhaust

1шт.

16

A58895

GASKET

- exhaust manifold

4шт.

17

A59077

STUD

- 3/8" NC x 1-3/4", exhaust manifold

8шт.

18

92-6

LOCK WASHER,3/8"

exhaust manifold 3/8"

8шт.

19

131-903

NUT,3/8"-16

NUT - 3/8" NC hex, Seezpruf, exhaust manifold

8шт.
