Артикул
Название
Примечание
Количество
S514199
VALVE
- 4 spool main control, Includes: Ref. 1 - 39
1шт.
S610388
VALVE - basic, Includes: Ref. 1 - 35
1шт.
1
S116121
CAP
4шт.
3
S116126
SPRING
4шт.
4
S116120
VALVE, CHECK
CHECK
4шт.
5
NSS
NOT SOLD SEPARAT
BODY - valve
1шт.
6
S116131
O-RING,0.139" Thk x 1.296" ID, -219, Cl 5, 75 Duro
1.290/1.302 ID
8шт.
7
S116127
SEAL
- wiper
4шт.
8
S116122
PLATE
4шт.
9
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
32шт.
13-412
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
32шт.
10
S116124
PLUG - orifice
1шт.
11
S116444
CAP
1шт.
12
S116443
O-RING
1шт.
13
S116442
KIT
VALVE - main relief, Includes: Ref. 14 - 26
1шт.
14
S116119
SEAT
- relief
1шт.
15
D72745
VALVE
CHECK
1шт.
16
D82724
SPRING
1шт.
17
A7982
O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro
1шт.
18
S116118
VALVE POPPET
POPPET
1шт.
19
D24762
VALVE
POPPET
1шт.
20
D24763
SPRING
1шт.
21
F62075
O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro
1шт.
22
S82718
CAP
1шт.
23
D26763
WASHER
2шт.
24
25-158
JAM NUT,Jam, 1/2"-20, G5
- jam
1шт.
25
L32298
ADJUSTMENT SCREW,1/2" - 20 x 1.50"
- adjustable
1шт.
26
L32299
NUT
- acorn
1шт.
27
S116125
RING
- backup
4шт.
28
S116123
PLATE
4шт.
29
REF
INSTRUCTION
PLUNGER - (See Figure 303A)
1шт.
30
S116130
COVER
4шт.
31
S83096
PLUG
- bleeder
4шт.
32
REF
INSTRUCTION
PLUNGER - (See Figure 303A)
2шт.
33
REF
INSTRUCTION
PLUNGER - (See Figure 303A)
1шт.
34
S116129
CAP
1шт.
35
S116128
O-RING,0.949" OD x 0.097" Width
1шт.
36
S8985
PLUG
1шт.
S6069
O-RING,1.171" ID x 0.116" Width
1шт.
37
REF
INSTRUCTION
VALVE - relief - (Set at 2500 PSI) - (See Figure 303C)
4шт.
38
REF
INSTRUCTION
VALVE - relief - (Set at 3200 PSI) - (See Figure 303C)
2шт.
39
S237978
PLUG
2шт.
S116368
O-RING
2шт.
S116369
O-RING
2шт.
40
S13432
BOLT - 1/2" x 5-1/4" NC hex (valve mounting) (Replaces S113428)
3шт.
41
S115695
SPACER
- (below valve)
3шт.
42
131-70
NUT,1/2"-13, GB
NUT - lock 1/2" NC hex
3шт.
