Запчасти Case 980 (076) - CAB (05) - UPPERSTRUCTURE CHASSIS

NSS

NOT SOLD SEPARAT

CAB ASSEMBLY (MACHINERY ITEM)

1шт.

1

173-95

SCREW,Sl Rnd Hd, #10 - 24 x 3/8"

machine - 10 NC x 3/8"

7шт.

2

S222614

CHANNEL

1шт.

3

S95515

INSULATION, accoustical

1шт.

4

S222610

INSULATION, accoustical

1шт.

5

S95512

INSULATION, accoustical

1шт.

6

S95506

INSULATOR

INSULATION, accoustical

1шт.

7

S95504

INSULATION, accoustical

2шт.

8

S95511

INSULATION, accoustical

1шт.

9

174-95

SCREW,Sl Rd Hd, #10 - 32 x 3/8"

machine - 10 NF x 3/8"

4шт.

10

S222613

ANGLE

1шт.

11

S95516

NUT

lock - No. 10 NF

4шт.

12

S222611

INSULATION, accoustical

1шт.

13

S95507

INSULATOR

INSULATION, accoustical

1шт.

14

S95501

INSULATOR

INSULATION, accoustical

1шт.

15

S95514

INSULATOR

INSULATION, accoustical

1шт.

16

S507325

FRAME

1шт.

17

S95505

INSULATOR

INSULATION, accoustical

2шт.

18

S222612

INSULATOR

INSULATION, accoustical

1шт.

19

S95509

INSULATOR

INSULATION, accoustical

1шт.

20

S95508

INSULATOR

INSULATION, accoustical

1шт.

21

S222609

INSULATION, accoustical

1шт.

22

S95517

ADHESIVE

(NOT ILLUSTRATED)

1шт.
