Запчасти Case 1088 (7-12) - TURNTABLE LEVELER HYDRAULIC LINES, P.I.N. FROM 106901 AND AFTER (07) - BRAKES

1

P3237533

UNION

ADAPTER - straight

4шт.

P1145268

SEAL

O-RING - adapter, not shown

1шт.

2

P5431967

HOSE

- 24-13/16" long, Serial Range: return-swivel

1шт.

3

P5431963

HOSE

- 24-13/16" long, pressure

1шт.

4

P3237530

UNION

ADAPTER - straight

5шт.

P7046042

SEAL

- adapter, not shown

1шт.

5

P5931904

HOSE

- 19-3/4" long, pilot, leveler, Serial Range: valve-swivel

2шт.

6

REF

INSTRUCTION

VALVE - cylinder check control, (See Figure 7-24)

2шт.

7

P32905

SCREW

BOLT - socket, 8 mm x 55 mm

4шт.

8

P5431969

HOSE

- 39-3/8" long, cylinder check valve, right-hand side to left-hand side

2шт.

9

P3237583

UNION

ADAPTER - straight

4шт.

P1145268

SEAL

- adapter, not shown

1шт.

10

P4837508

UNION

REDUCER - straight

2шт.

P2230418

SEAL

O-RING - adapter, not shown

1шт.

11

P3237532

UNION

ADAPTER - straight

2шт.

P2230418

SEAL

O-RING - reducer, not shown

1шт.

12

P8947606

PIPE

TUBE - leveler control valve to check valve, right-hand side

1шт.

13

P8947605

PIPE

TUBE - leveler control valve to check valve, left-hand side

1шт.

14

P4837541

FITTING

VALVE - no return valve, at cylinder

4шт.

P2230418

SEAL

O-RING - adapter, not shown

1шт.

15

P7631909

HOSE

- 15-3/4" long, cylinder to check valve

4шт.

16

P4237510

UNION

ADAPTER - straight

4шт.

P2230418

SEAL

O-RING - adapter, not shown

1шт.

17

P51946

CLAMP

TIE STRAP - hoses, 10-1/8" long

1шт.

18

P7631912

HOSE

- 78-3/4" long, pressure sensing, (See Figure 7-4 for continuation Ref. 10), Serial Range: 106901-106939

1шт.

18

P7931911

HOSE

- 2000 mm long, pressure sensing, (See Figure 7-5A for continuation Ref. 9), Start Serial: 106940

1шт.

19

P2643351

BLOCK ASSY.

TEE - power sensing hoses

1шт.

20

P3237554

FITTING

ADAPTER - straight

1шт.

P7046042

SEAL

- adapter, not shown

1шт.

21

P7931907

HOSE

- 24-13/16" long, pressure sensing, leveler control valve to swivel, (Replaces P6531955)

1шт.

22

P2537413

PLUG

- hex socket, 22 mm

2шт.

P1145268

SEAL

- adapter, not shown

1шт.

23

P2537412

PLUG

- hex socket, 22 mm

2шт.

P2230418

SEAL

O-RING - reducer, not shown

1шт.

24

P1737018

ANGLE

ELBOW - 90 degree

1шт.
