Запчасти Case 1088 (156) - ENGINE ACCELERATION (0.80 M) (10) - ENGINE

1

SUPPORT see standard catalog

1шт.

2

SCREW, M6 x 16, see standard catalog

2шт.

3

WASHER 6.25 x 4 x 15, see standard catalog

2шт.

4

NUT, M6, see standard catalog

2шт.

5

LEVER see standard catalog

1шт.

6

RING self lub, 14 x 18 x 28, see standard catalog

1шт.

7

WASHER see standard catalog

1шт.

8

WASHER see standard catalog

2шт.

9

WASHER, M14 N, see standard catalog

2шт.

10

NUT, M14, see standard catalog

1шт.

11

NUT, M14, see standard catalog

1шт.

12

KNOB see standard catalog

1шт.

13

IDEOGRAM see standard catalog

1шт.

14

FORK see standard catalog

2шт.

15

A4831357

CABLE

1шт.

16

LOCK see standard catalog

1шт.

17

SCREW, M6 x 30 x 30, see standard catalog

2шт.

18

WASHER 6.25 x 4 x 15, see standard catalog

4шт.

19

NUT safety, M6, see standard catalog

2шт.
