Запчасти Case 1080B (6-154) - TRACK DRIVE HYDRAULIC LINES - LOWER, P.I.N. 6271846 AND AFTER (06) - POWER TRAIN

1

S618820

LINK

SWIVEL ASSEMBLY - hydraulic, parts list Figure 8-256

1шт.

2

218-5124

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

at swivel ports No. 2, 3, 6 and 7, Includes: Ref. 3 90º, 1 5/16"-12, 37º x 1 1/16"-12, O-Ring

4шт.

3

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk, Elbow

1шт.

4

218-5354

HYD CONNECTOR,9/16"-18, 37 Degree x 7/8"-14, O-Ring

FITTING, 9/16"-18, 37° x 7/8"-14, O-Ring, At swivel port No. 1, Includes Ref. 5

1шт.

5

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

10-1, 90 Duro, .755" ID x .097" Thk, Adapter

1шт.

6

218-980

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw

- 90 degree, at swivel port No. 1

1шт.

7

S241220

HOSE ASSY.

HOSE - 70" (1778 mm), Serial Range: long,-swivel

1шт.

8

S120647

HOSE ASSY.

HOSE - 52" (1321 mm) long, track drive circuits

2шт.

9

S8626

HOSE ASSY.

HOSE - 60" (1524 mm) long, track drive circuits

2шт.

10

218-5110

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB

at drive motors, Incl. Ref. 11 90º, 1 5/16"-12, 37º x 1 5/16"-12, O-Ring

4шт.

11

237-6016

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

- elbow

1шт.

12

S517083

MOTOR, HYDRAULIC

MOTOR ASSEMBLY - hydraulic, track drive, right-hand, parts list Figure 6-162

1шт.

13

S517084

MOTOR, HYDRAULIC

MOTOR ASSEMBLY - hydraulic, track drive, left-hand, parts list Figure 6-162

1шт.

14

218-5278

ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB

- 90 degree, left-hand motor "T" port, Incl. Ref. 15

1шт.

15

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk, Elbow

1шт.

16

S241217

HOSE ASSY.

HOSE - 21" (533 mm) long, motor drain port

1шт.

17

218-5222

TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run

hose to tee 37º, 9/16"-18, x 9/16"-18, Fem Sw Run

1шт.

18

218-1240

FITTING

TEE - bulkhead, tee connecting

1шт.

19

218-1254

LOCK NUT,Blkhd, 9/16"-18

NUT - hex, 9/16" -18 NF, bulkhead tee

1шт.

20

218-5222

TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run

hose to tee 37º, 9/16"-18, x 9/16"-18, Fem Sw Run

1шт.

21

S242341

HOSE ASSY.

HOSE - 27-1/2" (699 mm) long, Serial Range: tee-adapter

2шт.

22

218-443

HYD CONNECTOR,9/16" - 18 Male JIC x 1/4" - 18 Male NPTF

ADAPTER - straight, motor drain port

2шт.

23

S241217

HOSE ASSY.

HOSE - 21" (533 mm) long, motor drain port

1шт.

24

218-5278

ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB

- 90 degree, right-hand motor "Y" port, Incl. Ref. 25

1шт.

25

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk, Elbow

1шт.

26

S98324

CLAMP

- hose

4шт.

27

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

1шт.
