Запчасти Case 9060B (9-086) - LUBRICATION FOR 3.36 M (11 FOOT) ARM (09) - CHASSIS

1

REF

INSTRUCTION

ARM ASSEMBLY - excavator, 3.36 M (11 ft) long, parts list Figure 9-90

1шт.

2

151703A1

TUBE ASSY.,995.5, 260.3 mm Length

TUBE ASSEMBLY - lubrication

1шт.

3

157255A1

TUBE ASSY.

TUBE ASSEMBLY - lubrication

1шт.

4

152032A1

UNION

CONNECTOR - straight

1шт.

5

152627A1

ELBOW

- 90 degree, special

1шт.

6

168377A1

CLAMP

- lubrication line, single type

3шт.

7

614-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd

HH, CL 8.8, M8 x 1.25 x 30

3шт.

8

892-11008

LOCK WASHER,8mm ID

WASHER, LOCK, M8

3шт.

9

153631A1

LUBE NIPPLE,1/8"-27 NPT

FITTING - grease, 45 degree

2шт.

10

152599A1

MULTIPOLE CONNECTOR

CONNECTOR - straight, special

2шт.

11

153630A1

LUBE NIPPLE

FITTING - grease, straight

1шт.

12

152776A1

HOSE,560.00 mm

560.00 mm

1шт.
