Запчасти Case 9050B (9-6[A]) - COUNTERWEIGHT TIMBER KING MODELS P.I.N. EAC0531007 AND AFTER (09) - CHASSIS

1

173495A1

GEAR, RING

COUNTERWEIGHT - rear, 8410 kg (18,502 lbs)

1шт.

2

REF

INSTRUCTION

INSULATION - acoustic, not used in this application

1шт.

3

REF

INSTRUCTION

INSULATION - acoustic, not used in this application

1шт.

4

REF

INSTRUCTION

INSULATION - acoustic, not used in this application

1шт.

5

173238A1

BOLT

- hex, special

6шт.

6

REF

INSTRUCTION

WASHER - flat, not used in this application

1шт.

7

REF

INSTRUCTION

PLUG - special, not used in this application

1шт.

8

162585A1

ADJUSTING PLATE

SHIM - counterweight, 0.77 mm (.03 inch) thick

1шт.

9

162586A1

ADJUSTING PLATE

SHIM - counterweight, 1.27 mm (.05 inch) thick

1шт.

10

162587A1

ADJUSTING PLATE

SHIM - counterweight, 2.29 mm (.09 inch) thick

1шт.

11

162588A1

ADJUSTING PLATE

SHIM - counterweight, 4.58 mm (.18 inch) thick

1шт.

12

162589A1

ADJUSTING PLATE

SHIM - counterweight, 6.35 mm (.25 inch) thick

1шт.

13

173233A1

WASHER

- high strength, special

6шт.

14

REF

INSTRUCTION

BRACKET - counterweight mounting, not used in this application

1шт.

15

REF

INSTRUCTION

BOLT - hex, not used in this application

1шт.

16

REF

INSTRUCTION

WASHER - lock, 12 mm, not used in this application

1шт.
