Запчасти Case 9050B (8-150) - HYDRAULIC PUMP, REGULATOR COVER (08) - HYDRAULICS
№
Артикул
Название
Примечание
Количество
NSS
NOT SOLD SEPARAT
COVER ASSEMBLY - regulator, Includes: Ref. 1 - 52
1шт.
1
NSS
NOT SOLD SEPARAT
HOUSING - regulator cover
1шт.
2
NSS
NOT SOLD SEPARAT
VALVE ASSEMBLY - throttle, parts list figure 8-146
1шт.
3
NSS
NOT SOLD SEPARAT
PLUG - port
26шт.
4
NSS
NOT SOLD SEPARAT
PLUG - port
3шт.
5
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
7
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
8
154467A1
O-RING,10.8mm ID x 2.4mm Width
plug
1шт.
9
NSS
NOT SOLD SEPARAT
GUIDE - valve
2шт.
10
NSS
NOT SOLD SEPARAT
BALL - valve
2шт.
11
NSS
NOT SOLD SEPARAT
SEAT - valve
2шт.
12
NSS
NOT SOLD SEPARAT
PLUG - port
2шт.
13
154467A1
O-RING,10.8mm ID x 2.4mm Width
plug
2шт.
14
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
15
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
16
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
17
NSS
NOT SOLD SEPARAT
SLEEVE - valve
1шт.
18
NSS
NOT SOLD SEPARAT
BALL - valve
1шт.
19
NSS
NOT SOLD SEPARAT
PACKING - valve
1шт.
20
NSS
NOT SOLD SEPARAT
PLUG - retaining
1шт.
21
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
22
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
23
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
24
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
25
NSS
NOT SOLD SEPARAT
SLEEVE - valve
1шт.
26
NSS
NOT SOLD SEPARAT
BALL - valve
1шт.
27
NSS
NOT SOLD SEPARAT
PACKING - valve
1шт.
28
NSS
NOT SOLD SEPARAT
PLUG - retaining
1шт.
29
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
30
155352A1
FILTER CARTRIDGE
ELEMENT - filter
1шт.
31
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
32
NSS
NOT SOLD SEPARAT
SCREW - adjusting
1шт.
33
154443A1
O-RING
screw
1шт.
34
153937A1
BACK-UP RING
backup
1шт.
35
829-1308
NUT,M8, Cl 10
Adjusting screw locking
1шт.
36
156363A1
CAP
adjustment
1шт.
37
155352A1
FILTER CARTRIDGE
ELEMENT - filter
1шт.
38
NSS
NOT SOLD SEPARAT
PLUG - port
1шт.
39
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
40
NSS
NOT SOLD SEPARAT
SLEEVE - valve
1шт.
41
154471A1
O-RING
bushing
1шт.
42
NSS
NOT SOLD SEPARAT
COVER - valve
1шт.
43
861-6012
HEX SOC SCREW,M6 x 12mm, Cl 12.9
hex socket, 6 - 1.0 x 12 mm, class 12.9
1шт.
44
861-6020
HEX SOC SCREW,M6 x 20mm, Cl 12.9
2шт.
45
NSS
NOT SOLD SEPARAT
SPOOL - valve
1шт.
46
NSS
NOT SOLD SEPARAT
SLEEVE - valve
1шт.
47
NSS
NOT SOLD SEPARAT
PISTON - valve
1шт.
48
NSS
NOT SOLD SEPARAT
BUSHING - passage
2шт.
49
155191A1
O-RING
passage
2шт.
50
155207A1
O-RING
passage
2шт.
51
155206A1
O-RING
passage
2шт.
52
863-10075
HEX SOC SCREW,M10 x 75mm, 12.9
8шт.
Выбрано товаров: 53
