Запчасти Case 9010B (8-030) - BOOM CONTROL LINES (08) - HYDRAULICS

1

161842A1

ADAPTER,3/8" - 19 NPT x 1/4" - 19 ORB

- straight, Includes: Ref. 2

1шт.

2

154467A1

O-RING,10.8mm ID x 2.4mm Width

- adapter

1шт.

3

159211A1

HYDRAULIC HOSE

HOSE - 2000 mm (78-3/4 inch) long, boom-up control line, right hand console to shuttle valve (controller port 4 to shuttle valve port A3)

1шт.

4

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 5

1шт.

5

154475A1

O-RING

- adapter

1шт.

6

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 7

1шт.

7

154475A1

O-RING

- adapter

1шт.

8

159223A1

HOSE ASSY.

HOSE - 1100 mm (44-3/16 inch) long, boom-up control line (shuttle valve port B3 to cushion valve port F)

1шт.

9

153120A1

HYD CONNECTOR

ADAPTER - straight, replaces 152128A1 adapter, Includes: Ref. 10

1шт.

10

154486A1

O-RING

- adapter, replaces 154475A1 O-ring

1шт.

11

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 12

1шт.

12

154475A1

O-RING

- adapter

1шт.

13

159224A1

HOSE ASSY.

HOSE - 900 mm (35-7/16 inch) long, boom-up control line (cushion valve port H to control valve port br1)

1шт.

14

152747A1

ADAPTER

- straight, Includes: Ref. 15

1шт.

15

154467A1

O-RING,10.8mm ID x 2.4mm Width

- adapter

1шт.

16

152127A1

HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT

ADAPTER - straight, Includes: Ref. 17

1шт.

17

154467A1

O-RING,10.8mm ID x 2.4mm Width

- adapter

1шт.

18

152704A1

HOSE

- 1800 mm (71 inch) long, Boom-up/down control line (Shuttle valve port C3 to control valve port ar11)

1шт.

19

150913A1

ELBOW,90 Degree, 1/4" O-Ring x 1/4"

- 90 degree, Includes: Ref. 20

1шт.

20

154467A1

O-RING,10.8mm ID x 2.4mm Width

- elbow

1шт.

21

152127A1

HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT

ADAPTER - straight, Includes: Ref. 22

1шт.

22

154467A1

O-RING,10.8mm ID x 2.4mm Width

- adapter

1шт.

23

151895A1

HOSE,2450.00 mm

- Boom-up control line (Shuttle valve port C2 to control valve port d) 2450.00 mm

1шт.

24

150913A1

ELBOW,90 Degree, 1/4" O-Ring x 1/4"

- 90 degree, Includes: Ref. 25

1шт.

25

154467A1

O-RING,10.8mm ID x 2.4mm Width

- elbow

1шт.

26

161842A1

ADAPTER,3/8" - 19 NPT x 1/4" - 19 ORB

- straight, Includes: Ref. 27

1шт.

27

154467A1

O-RING,10.8mm ID x 2.4mm Width

- adapter

1шт.

28

159212A1

HYDRAULIC HOSE,9.50 mm ID x 2100.00 mm

- Boom-down control line (RH controller port 2 to shuttle valve port A4) 9.50 mm ID x 2100.00 mm

1шт.

29

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 30

1шт.

30

154475A1

O-RING

- adapter

1шт.

31

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 32

1шт.

32

154475A1

O-RING

- adapter

1шт.

33

159224A1

HOSE ASSY.

HOSE - 900 mm (35-7/16 inch) long, boom-down control line (shuttle valve port B4 to cushion valve port E)

1шт.

34

153120A1

HYD CONNECTOR

ADAPTER - straight, replaces 152128A1 adapter, Includes: Ref. 35

1шт.

35

154486A1

O-RING

- adapter, replaces 154475A1 O-ring

1шт.

36

152128A1

HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT

ADAPTER - straight, Includes: Ref. 37

1шт.

37

154475A1

O-RING

- adapter

1шт.

38

161175A1

HOSE ASSY.

HOSE - 1550 mm (61 inch) long, boom-down control line (cushion valve port G to control valve port ar1)

1шт.

39

153559A1

ELBOW

- 90 degree, models without load hold, Includes: Ref. 40

1шт.

40

154467A1

O-RING,10.8mm ID x 2.4mm Width

- elbow, models without load hold

1шт.

41

162827A1

TEE

- special, models with load hold, Includes: Ref. 42

1шт.

42

154467A1

O-RING,10.8mm ID x 2.4mm Width

- tee, models with load hold

1шт.

43

159223A1

HOSE ASSY.

HOSE - 1100 mm (44-3/16 inch) long, models with load hold

1шт.

44

153495A1

ADAPTER

ELBOW - 90 degree, models with load hold

1шт.

45

161976A1

TEE

- special, models with load hold, see Figure 8-62, Ref. 2 for connections

1шт.

46

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

- hex, full threads, 10 - 1.5 x 25 mm, class 10.9, Models with load hold

2шт.

47

150409A1

WASHER

- flat, special, 10.5 x 21 x 3.2 mm, models with load hold

2шт.
