40
166052A1
BOLT
2шт.
41
163287A1
STUD
Consists Of Ref. Number : 41A
1шт.
41a
154487A1
O-RING
1шт.
42
167235A1
TUBE ASSY.
1шт.
43
167242A1
HYDRAULIC HOSE
1шт.
44
159372A1
ELBOW
Consists Of Ref. Number : 44A
2шт.
44a
154503A1
O-RING
1шт.
45
159485A1
VALVE
1шт.
46
153622A1
ADAPTER
1шт.
47
159490A1
VALVE
1шт.
48
151002A1
PLUG
1шт.
49
157685A1
HYD CONNECTOR
Consists Of Ref. Number : 49A
1шт.
49a
154503A1
O-RING
1шт.
50
167230A1
MANIFOLD
1шт.
51
152924A1
PLUG
Consists Of Ref. Number : 51A
1шт.
51a
154503A1
O-RING
1шт.
52
154569A1
O-RING
1шт.
53
827-8080
BOLT,Hex, M8 x 1.25 x 80mm, Cl 10.9
4шт.
54
892-11008
LOCK WASHER,8mm ID
4шт.
55
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
56
163278A1
FILTER
Consists Of Ref. Numbers : 56A, 56B
1шт.
56a
163279A1
HYDRAULIC OIL FILTER
1шт.
56b
159706A1
INDICATOR
1шт.
57
167239A1
BRACKET
1шт.
59
166352A1
BOLT
2шт.
60
150811A1
WASHER
M12
4шт.
61
164176A1
ADAPTER
Consists Of Ref. Number : 61A
1шт.
61a
154487A1
O-RING
1шт.
62
167252A1
TUBE ASSY.
1шт.
63
167244A1
HYDRAULIC HOSE
1шт.
64
159748A1
VALVE
1шт.
65
163271A1
HYD CONNECTOR
Consists Of Ref. Number : 65A
1шт.
65a
154503A1
O-RING
2шт.
66
167243A1
HYDRAULIC HOSE
1шт.
67
167236A1
TUBE ASSY.
1шт.
68
167229A1
HYDRAULIC HOSE
1шт.
58
827-10045
BOLT,Hex, M10 x 1.5 x 45mm, Cl 10.9
4шт.
69
167228A1
HYDRAULIC HOSE
1шт.
70
167233A1
COLLAR
1шт.
71
827-12050
BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9
2шт.
72
167247A1
BRACKET
1шт.
73
627-12025
BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd
2шт.
74
167227A1
COLLAR
1шт.
75
167183A1
BOLT,Sems, M12 x 60mm, Cl 10.9
1шт.
76
151654A1
HYD CONNECTOR,3/4" NPT O-Ring x 3/4" NPT
Consists Of Ref. Number : 76A
1шт.
76a
154503A1
O-RING
1шт.
77
167248A1
FITTING
1шт.
78
150409A1
WASHER
10.5 x 21 x 3.2 mm
4шт.
