Запчасти Case 600 (052[1]) - INSTRUMENT INSTALLATION, COWL AND DASH, INSTRUMENTS, SWITCHES, GAUGES, (USED UP TO SERIAL #7060799) (06) - ELECTRICAL SYSTEMS

1

REF

INSTRUCTION

COWL & DASH ASSY - (See figure #124, ref. #10)

1шт.

2

NLS

NO LONGER SERVICED

ASSY - engine oil pressure

1шт.

3

35203

X

GAUGE ASSY - transmission oil pressure

1шт.

4

10838

ELECTRICAL GAUGE

ASSY - water temperature

1шт.

5

10860

X

AMMETER GAUGE ASSY - ammeter

1шт.

6

33267

CHAIN

SPARE PART METER ASSY - engine hours

1шт.

7

218-511

ELBOW,90º, 7/16"-20, 37º x 1/8"-27, Fem NPTF

1/8 NP x 1/4 SAE (50162)

1шт.

8

36562

DRIVING SPROCKET

HOSE ASSY - pressure gauge to pressure switch

1шт.

9

221-421

TEE,1/8" NPT

Pipe (41580)

1шт.

10

221-106

PIPE,Nipple, 1/8" NPT x 1 1/2"

(41415)

1шт.

11

221-411

ELBOW,90 Degree, 1/8"-27, NPT

Street (41670)

1шт.

12

10953

SPARE PART SWITCH ASSY - pressure

1шт.

13

10855

X

LIGHT SWITCH

1шт.

14

A10868

DECAL

SWITCH ASSY - ignition

1шт.

15

NLS

NO LONGER SERVICED

SWITCH ASSY - push button starter (10864)

1шт.

16

REF

INSTRUCTION

CHOKE ASSY - carburetor control (See page #56, ref. #1)

1шт.

17

REF

INSTRUCTION

THROTTLE ASSY - hand (See figure #56, ref. #2)

1шт.

18

49861

O-RING,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro

BUTTON - plug

2шт.
