Запчасти Case 600 (150) - TERRALOADR HYDRAULIC INSTALLATION, PUMP, VALVE HOSES, TUBING, FITTINGS (USED UP TO S/N 7060799) (07) - HYDRAULIC SYSTEM

60

25-115

NUT,5/16"-24, G5

- reg. SF hex (5/16"-24 NF) (48101)

1шт.

61

218-615

TEE,7/8"-14, 37 Degree x 1/2"-14, NPTF Run

- male run, 5/8 JIC and 1/2 NP (50226)

1шт.

62

33960

RIVET

TUBE ASS'Y. - valve to relief valve

1шт.

63

33959

PIPE FITTING

VALVE ASS'Y. - relief (See figure #278 for breakdown)

1шт.

64

33958

ELBOW - lateral, 90 degree

1шт.

65

19242

BUSHING

TUBE ASS'Y. - relief, Serial Range: valve-valve

1шт.

66

218-486

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 3/4" - 14 Male NPTF

- 90 degree male, 3/4 JIC to 3/4 NP (50116)

1шт.

67

35582

HOSE

ASS'Y. - valve to manifold, dump cylinder hydraulic system

2шт.

68

218-445

HYD CONNECTOR,7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

CONNECTOR - male, 5/8 JIC to 1/2 NP (50024), dump cylinder hydraulic system

1шт.

69

19267

TUBE ASS'Y. - manifold, rear ports, dump cylinder hydraulic system

1шт.

70

19269

TUBE ASS'Y. - manifold, front ports, dump cylinder hydraulic system

1шт.

71

19268

SELF-TAP SCREW,Hex Hd, #10 x 1/2"

HOSE & TUBE ASS'Y. - manifold to dump cyl. (Used up to serial #3-16-56) hydraulic system

2шт.

33998

HOSE & TUBE ASS'Y. - manifold to dump cyl. (Used from serial #3-16-56 and up to serial #12-24-56) hydraulic system

2шт.

72

36582

TUBE ASS'Y. - manifold to dump cylinder (Used from serial #12-24-56) hydraulic system

2шт.

73

36547

HOSE

ASS'Y. - manifold to dump cylinder (Used from serial #12-24-56) hydraulic system

2шт.

74

19270

HOSE & TUBE ASS'Y. - manifold to dump cyl. (Used up to serial #3-16-56) hydraulic system

2шт.

33999

X,0.625" OD

HOSE & TUBE ASS'Y. - manifold to dump cyl. (Used from serial #3-16-56 and up to serial #12-24-56) hydraulic system

2шт.

75

36592

TUBE ASS'Y. - manifold to dump cylinder (Used from serial #12-24-56) hydraulic system

2шт.

76

NLS

NO LONGER SERVICED

HOSE ASS'Y. - manifold to dump cylinder (Used from serial #12-24-56) hydraulic system

2шт.

77

36594

FIXING PLATE

TUBE ASS'Y. - manifold to dump cylinder (Used from serial #12-24-56) hydraulic system

2шт.

78

218-485

ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

- 90 degree male, 5/8 JIC to 1/2 NP (50114), dump cylinder hydraulic system

4шт.

79

32978

PLATE ASSY.

CLAMP - tube, dump cylinder hydraulic system

12шт.

80

14-528

BOLT,Hex, 5/16" - 24 x 1-3/4", Gr 5

(32978 mtg.) (45634), Dump cylinder hydraulic system Hex, 5/16"-24 x 1 3/4", G5

6шт.

81

92-5

LOCK WASHER,5/16"

(48445), dump cylinder hydraulic system 5/16"

6шт.

82

25-115

NUT,5/16"-24, G5

- reg. SF hex (5/16"-24 NF) (48101), dump cylinder hydraulic system

2шт.

83

218-445

HYD CONNECTOR,7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

CONNECTOR - male, 5/8 JIC to 1/2 NP (50024), lift cylinder hydraulic system

2шт.

84

19259

HOSE ASS'Y. - valve to manifold, lift cylinder hydraulic system

1шт.

85

19262

HOSE ASS'Y. - valve to manifold, lift cylinder hydraulic system

1шт.

86

19260

TUBE ASS'Y. - manifold, rear ports, lift cylinder hydraulic system

1шт.

87

19263

TUBE ASS'Y. - manifold, front ports, lift cylinder hydraulic system

1шт.

88

19261

HOSE & TUBE ASS'Y. - manifold to lift cylinder (Used up to serial #12-24-56) hydraulic system

2шт.

89

36576

TUBE ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

90

36695

HOSE ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

91

36578

TUBE ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

92

36574

HOSE

HOSE & TUBE ASS'Y. - L.H., manifold to lift cylinder (Used up to serial #12-24-56) hydraulic system

1шт.

93

19265

X

HOSE & TUBE ASS'Y. - R.H. , manifold to lift cylinder (Used up to serial #12-24-56) hydraulic system

1шт.

94

36576

TUBE ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

95

36574

HOSE

ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

96

36588

TUBE ASS'Y. - manifold to lift cylinder (Used from serial #12-24-56) hydraulic system

2шт.

97

218-485

ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

- 90 degree male, 5/8 JIC to 1/2 NP (50114), lift cylinder hydraulic system

3шт.

98

33888

ELBOW - 90 degree special, lift cylinder hydraulic system

1шт.

99

221-11

PLUG,Sq Hd, 1/8"-27

- pipe, ext. sq. head, 1/8 NP (41820), lift cylinder hydraulic system

1шт.

100

32978

PLATE ASSY.

CLAMP - tube, lift cylinder hydraulic system

6шт.

101

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

HHCS 5/16-24 NF x 1 (32978 mt'g.) (45631), lift cylinder hydraulic system

4шт.

102

92-5

LOCK WASHER,5/16"

(48445), lift cylinder hydraulic system 5/16"

4шт.

103

25-115

NUT,5/16"-24, G5

- reg. SF hex (5/16"-24 NF) (48101), lift cylinder hydraulic system

4шт.
