Запчасти Case 600 (146) - DRAWBAR INSTALLATION - STANDARD (INDUSTRIAL), DRAWBAR, GUIDE, MTG. PARTS (04) - UNDERCARRIAGE

1

13103

GUIDE - drawbar

1шт.

2

32330

BEVEL PINION

BRACKET - RH

1шт.

3

32331

BRACKET - LH

1шт.

4

14-1032

BOLT,Hex, 5/8" - 18 x 2", Gr 5

(32330 & 32331 mt'g.) (45760) Hex, 5/8"-18 x 2", G5

2шт.

5

14-1024

BOLT,Hex, 5/8" - 18 x 1-1/2", Gr 5

(32330 & 32331 mt'g.) (45758) Hex, 5/8"-18 x 1 1/2", G5

2шт.

6

92-10

LOCK WASHER,5/8"

WASHER, LOCK, (48450) 5/8"

4шт.

7

14-1032

BOLT,Hex, 5/8" - 18 x 2", Gr 5

(13103 mt'g.) (45760) Hex, 5/8"-18 x 2", G5

4шт.

8

92-10

LOCK WASHER,5/8"

WASHER, LOCK, (48450) 5/8"

4шт.

9

25-1110

NUT,5/8"-18, G5

- reg. SF hex (5/8-18 NF) (48106)

4шт.

10

32337

DRAWBAR - industrial

1шт.

11

33817

ANGLE

DRAWBAR - agricultural, Serial Range: (Optional-32337)

1шт.

12

37721

HUB

DRAWBAR - for scarifier, Serial Range: (Optional-32337)

1шт.

13

13043

BUSHING

HITCH - drawbar

2шт.

14

NSS

NOT SOLD SEPARAT

HOOK-OVER ASS'Y. - drawbar (Used up to serial #6-18-56) (Order ref. #15 & #16)

1шт.

15

NLS

NO LONGER SERVICED

SPACER - hook-over (Used from serial #6-8-56)

1шт.

16

NLS

NO LONGER SERVICED

STRAP - hook-over (Used from serial #6-18-56)

1шт.

17

14-1272

BOLT,Hex, 3/4" - 16 x 4-1/2", Gr 5

HHCS 3/4-16 NF x 4 1/2 (13043, 13107 & 13108 mt'g.) (45794)

2шт.

18

92-12

LOCK WASHER,3/4"

WASHER, LOCK, (48452) 3/4"

2шт.

19

25-1112

NUT,3/4"-16, G5

- reg. SF hex (3/4-16 NF) (48107)

2шт.

20

13073

AXLE PIN

PIN ASS'Y. - hitch

1шт.

21

13044

NUT

PIN (32337 mt'g.)

1шт.

22

132-154

COTTER PIN,1/4" x 2"

Pin, Split (Cotter), (48739) 1/4" x 2"

1шт.

6237

DRAWBAR INSTALLATION - heavy duty, (optional equipment)

1шт.

1

34944

CABLE

DRAWBAR ASS'Y. - heavy duty, (optional equipment)

1шт.

2

70989

PIN ASS'Y. - (34944 mt'g.), drawbar installation - heavy duty (optional equipment)

1шт.

6238

SPRING

DRAWBAR INSTALLATION - heavy duty (Scarifier), (optional equipment)

1шт.

1

34947

DRAWBAR ASS'Y. - heavy duty (Scarifier), (optional equipment)

1шт.

2

70989

PIN ASS'Y. (34947 mt'g.), drawbar installation - heavy duty (optional equipment)

1шт.

R-2469

DRAWBAR INSTALLATION - heavy duty (Scarifier), (optional equipment for scarifier only)

1шт.

1

37721

HUB

DRAWBAR - heavy duty, (optional equipment for scarifier only)

1шт.

2

37722

NUT

PLATE - drawbar installation - heavy duty (optional equipment for scarifier only)

1шт.

3

13044

NUT

PIN - drawbar installation - heavy duty (optional equipment for scarifier only)

1шт.

4

132-154

COTTER PIN,1/4" x 2"

Pin, Split (Cotter), (48739), Drawbar installation - heavy duty (optional equipment for scarifier only) 1/4" x 2"

1шт.

5

14-856

BOLT,Hex, 1/2" - 20 x 3-1/2", Gr 5

HHCS 1/2-20 N.F. x 3-1/2 (37722 mtg.) (45716), drawbar installation - heavy duty (optional equipment for scarifier only)

2шт.

6

92-8

LOCK WASHER,1/2"

(48448) , drawbar installation - heavy duty (optional equipment for scarifier only) 1/2"

2шт.

7

25-118

NUT,1/2"-20, G5

- reg. S.F. hex. (1/2-20 N.F.) (48104), drawbar installation - heavy duty (optional equipment for scarifier only)

2шт.
