Запчасти Case 520 (110[1]) - D21319 HYDRAULIC PUMP, 19 G.P.M., CODE NUMBER E9 AND LATER (07) - HYDRAULIC SYSTEM

1

D21319

PUMP - hydraulic (Webster No. 2 x ESI-L, 19 G.P.M.)

1шт.

2

D24860

COVER - pump

1шт.

3

F51079

NEEDLE BEARING

BEARING - needle

2шт.

4

D21334

PIN - dowel

2шт.

5

D21465

PLATE - wear

1шт.

6

34534

CAM

PLATE - gear

1шт.

7

D21343

GEAR - drive

1шт.

8

34625

GUARD

SHAFT - idler

1шт.

9

D21339

GEAR

- idler

1шт.

10

48777

X

KEY - Woodruff, idler gear

1шт.

11

38384

SNAP RING - idler gear

2шт.

12

D21466

PLATE - wear

1шт.

13

D24858

BODY - pump

1шт.

14

F51079

NEEDLE BEARING

BEARING - needle

1шт.

15

13-842

HHCS - 1/2 - 13NC x 2-5/8

4шт.

16

13-846

HHCS - 1/2 - 13NC x 2-7/8

2шт.

17

D23924

WASHER - lock

6шт.

18

D21340

X

SCREW - body (1/2 - 13 NC x 3 counter bore head)

2шт.

19

D21337

SHAFT - pump drive

1шт.

20

40200

BEARING ASSY,1.1811" ID x 2.4409" OD x 0.9375"

- ball, drive shaft

1шт.

21

34488

RING, SNAP

SNAP RING - bearing retaining

2шт.

22

D24862

PLATE

- polot, complete

1шт.

23

D24047

SEAL

- oil, (Double lip), pilot plate

1шт.

24

D24053

O-RING,0.103" Thk x 2.425" ID, -143, Cl 5, 75 Duro

SEAL - "O" ring

1шт.

25

73-48

SCREW,Slotted Flat Hd, 1/4"-20 x 1/2"

FHMS - 1/4 - 20 NC x 1/2

4шт.
