Артикул
Название
Примечание
Количество
73412
ADAPTER
PUMP - fuel injection
1шт.
1
73689
PISTON - power (1 degree advance)
1шт.
2
73677
HOUSING - automatic advance
1шт.
3
73679
SHROUD
WASHER - slide
2шт.
4
73683
SUN VISOR
SCREW - cam advance
1шт.
5
73451
PIN - drive shaft locating
1шт.
6
NLS
NO LONGER SERVICED
PISTON - spring (6 degree advance)
1шт.
7
73686
PANEL
SPRING - outer, advance
1шт.
8
73685
HYD CONNECTOR
SPRING - inner, advance
1шт.
9
51200273
SCREW
- idler adjusting
1шт.
10
73618
SPRING - plunger retaining
1шт.
11
73515
ROTOR ASS'Y - hydraulic head & distributor
1шт.
12
73522
SCREEN
SEAL - head
1шт.
13
51200832
SEAL ASSY.
SEAL - head locating screw
1шт.
14
73675
CYLINDER BLOCK
WASHER - advance body screw (Used with 73678 screw only)
1шт.
15
73678
SHROUD
SCREW - advance body clamp (Order R15706 for service)
1шт.
16
73647
GASKET - governor cover
1шт.
17
NLS
NO LONGER SERVICED
SEAL - cam hole
1шт.
18
RESERVED
1шт.
19
RESERVED
1шт.
20
73517
ROLLER - cam
2шт.
21
73516
SHOE - cam roller
2шт.
22
R19235
SPRING - main leaf
1шт.
23
73518
CUP
SCREW - leaf spring adjusting
1шт.
24
73520
SPRING - second leaf
1шт.
25
73521
SCREW
SPRING - third leaf
1шт.
26
R15707
PLATE - advance end (Power side)
1шт.
27
73681
FILTER
SCREW - stop
2шт.
28
73682
ELBOW
SPRING - ball check
1шт.
29
73680
SPARE PART
BALL - check
1шт.
30
73673
GROMMET
SEAL - automatic advance end plate
2шт.
31
73644
O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro
SEAL - advance stop screw
2шт.
32
73657
JET
LEVER ASS'Y - shut-off
1шт.
33
R15708
PLATE - advance end (Spring side)
1шт.
34
73690
SCREW - advance end plate
2шт.
35
R19236
RETAINER ASS'Y - governor weight
1шт.
36
73449
RING - drive shaft retaining
1шт.
37
73443
SHAFT - drive
1шт.
38
73448
PISTON
WASHER - drive shaft thrust
1шт.
39
R14711
SEAL
- drive shaft
2шт.
40
73633
SLEEVE - governor thrust
1шт.
41
73655
CARBURETOR
SHAFT - governor arm pivot
1шт.
42
73660
STEEL PLATE
RING - governor cage retaining
1шт.
43
73634
WASHER - governor thrust
1шт.
44
73635
WEIGHT - governor
6шт.
45
R15693
HOUSING & PILOT TUBE ASS'Y
1шт.
46
R15704
COVER - governor housing
1шт.
47
NLS
NO LONGER SERVICED
RETAINER - spring
1шт.
48
R11952
SPRING - idling
1шт.
49
73641
GUIDE - idling spring
1шт.
50
73664
SLEEVE - damper
1шт.
51
73665
DEFLECTOR
SPRING - damper
1шт.
52
74254
LEVER - throttle shaft
1шт.
53
R15702
ARM - governor
1шт.
54
73659
SHAFT
WASHER - pivot shaft seal
2шт.
55
73661
NUT - cap, pivot shaft
2шт.
56
R15701
HOOK ASS'Y - governor linkage
1шт.
57
73642
SPRING - governor control
1шт.
58
73638
SPRING - governor linkage
1шт.
59
73663
ELBOW
SPACER - throttle shaft lever
1шт.
60
413-840
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
SHAFT ASS'Y - throttle
1шт.
61
73644
O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro
SEAL - shut-off shaft, throttle shaft
2шт.
62
73658
REPAIR KIT
CAM - shut-off
1шт.
64
73652
SCREW - cover holddown (Order R22442 screw & R22443 washer for service)
3шт.
R22442
SCREW - cover holddown
3шт.
64a
R22443
WASHER
3шт.
65
73628
VALVE - metering
1шт.
66
73672
ROPE
WASHER - guide stud
1шт.
67
R15705
STUD - guide
1шт.
68
R15696
LINER - transfer pump
1шт.
69
RESERVED
1шт.
70
73610
HYD CONNECTOR
SEAL - transfer pump
1шт.
71
73607
ROTOR - transfer pump
1шт.
72
73666
AIR CLEANER
RING - filter nut seal
1шт.
73
73609
SOLENOID SWITCH
BLADE - transfer pump
2шт.
74
73627
X
PLUG - pipe, end plate
1шт.
75
74255
ARM - adjustable throttle
1шт.
76
73615
PLATE ASS'Y - plain end
1шт.
73616
PLATE - end
1шт.
73617
PIN - locating
1шт.
77
73671
ROPE
ELEMENT & FITTING ASS'Y - filter
1шт.
78
463-2086
SCREW,Slotted Hex Hd, #8-32 x 3/8"
- stop lever fitting
1шт.
79
73649
VOLTAGE REGULATOR
SCREW - throttle arm adjusting
2шт.
80
R19234
ARM ASS'Y - adjustable shut-off
1шт.
81
51200274
NUT
- lock, adjusting screw
4шт.
82
73630
LOCK WASHER
WASHER - lock, throttle arm & shut-off arm
2шт.
83
73670
SCREW
- throttle arm & shut-off arm retaining
2шт.
84
NSS
NOT SOLD SEPARAT
PLATE - name
1шт.
85
73645
SEALING RING COLLAR
- lock, positioning screw
2шт.
86
73646
SCREW
- adjusting, throttle arm & shut-off arm
2шт.
87
73613
SCREW
- fuel line connector
4шт.
88
73612
CONNECTOR, ELEC
CONNECTOR - fuel line
4шт.
89
73614
WASHER
- fuel line connector
8шт.
90
73611
SCREW - locking head
2шт.
91
NLS
NO LONGER SERVICED
- timing line cover
4шт.
92
73452
COVER
PLATE - timing line cover
2шт.
93
73623
PLUG - end plate
1шт.
94
73622
SPRING - regulator
1шт.
95
73620
X
RING - sleeve seal
2шт.
96
73619
SLEEVE - end plate
1шт.
97
NLS
NO LONGER SERVICED
- timing line cover
2шт.
98
73621
PISTON
- regulating
1шт.
99
R15698
SCREW - end plate
4шт.
100
73444
RING - cam
1шт.
101
NLS
NO LONGER SERVICED
SCREW - torque
1шт.
102
73632
NUT - torque screw seal
1шт.
103
73644
O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro
SEAL - torque screw
1шт.
104
73668
SCREW - throttle arm adjusting
1шт.
105
NSS
NOT SOLD SEPARAT
SCREW - name plate
2шт.
NSS
NOT SOLD SEPARAT
WIRE & LEAD PLOMB - seal (Not shown)
2шт.
73691
SHIM - advance spring (Not shown)
1шт.
R15699
SEAL - pivot shaft (Not shown)
2шт.
Выбрано товаров: 113
