Запчасти Case 350B (026) - MANIFOLDS, 188 DIESEL ENGINE (01) - ENGINE

1

A152536

MANIFOLD

ASSEMBLY - intake, Includes: Ref. 2 - 5

1шт.

2

221-849

PLUG,Hex Soc, 1/8"-27

- square head, 1/8" PT, intake manifold

1шт.

3

25-166

NUT,3/8"-16, G5, Hvy

- hex, 3/8" NC, intake manifold

5шт.

4

A50694

DISC

WASHER - with rubber insert, (Used with center and intermediate studs), intake manifold

3шт.

5

195-525

WASHER,3/8", SAE

- 3/8 x 13/16 x 1/16" (10 x 21 x 2 mm) (Used with end studs), intake manifold

2шт.

6

G46871

GASKET

- manifold to head, intake

1шт.

7

A140924

STUD

- end holes, 3/8 NC x 2-7/16", intake manifold

2шт.

8

A153248

STUD

- intermediate holes, 3/8 NC x 4-13/16", intake manifold

2шт.

9

A51500

STUD

- center hole, 3/8 NC x 5-5/16", intake manifold

1шт.

10

A20917

PLUG

- manifold heater hole, intake

1шт.

11

A20916

MANIFOLD GASKET

GASKET - heater hole plug, intake manifold

1шт.

15

A39233

MANIFOLD

ASSEMBLY - exhaust, Includes: Ref. 16 - 20

1шт.

16

A38188

PLATE

- cover, exhaust manifold

2шт.

17

G46853

MANIFOLD GASKET

- cover plate, exhaust manifold

2шт.

18

113-209

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

Cover plate, exhaust manifold Hex, 3/8"-16 x 1 1/2", G5

4шт.

19

195-525

WASHER,3/8", SAE

- 3/8 x 13/16 x 1/16" (10 x 21 x 2 mm), exhaust manifold

4шт.

20

131-903

NUT,3/8"-16

NUT - hex, Seez-Pruf, 3/8" NC, exhaust manifold

4шт.

21

G46872

MANIFOLD GASKET

- exhaust manifold

1шт.

22

A29431

STUD

- end holes, 3/8 NC x 1-3/4", exhaust manifold

2шт.

23

A140924

STUD

- manifold clamps, 3/8 NC x 2-7/16" (Replaces A39129), exhaust manifold

3шт.

24

A35028

CLAMP

- manifold, exhaust

3шт.

25

195-525

WASHER,3/8", SAE

- 3/8 x 13/16 x 1/16" (10 x 21 x 2 MM), exhaust manifold

5шт.

26

131-903

NUT,3/8"-16

NUT - hex, Seez-Pruf, 3/8" NC, exhaust manifold

5шт.
