Запчасти Case 350 (432) - DECALS (05) - UPPERSTRUCTURE CHASSIS

1

321-1438

DECAL

- Case, reflective, use 321-2425, early production

4шт.

1

321-2425

DECAL

- Case, non-reflective, early production

4шт.

2

321-1483

DECAL

- torque converter, early production

2шт.

3

321-1657

DECAL

- 350, early production

2шт.

4

321-1441

DECAL

- Case, reflective, use 321-1573, early production

1шт.

4

321-1573

DECAL

- Case, non-reflective, early production

1шт.

R24003

KIT

- decal, non-reflective decals and figure 435, early production

1шт.

5

321-1572

DECAL

- Case, RH, LH and center, dozer models, use with 321-3279 decal, late production

3шт.

Part of Decal Kit, P/N R41242

1шт.

6

321-2427

EMBLEM

DECAL - Case, RH and LH, loader models, use with 321-3116 decal, late production

2шт.

Part of Decal Kit, P/N R41242

1шт.

7

321-3107

DECAL

- 350, late production

2шт.

Part of Decal Kit, P/N R41242

1шт.

8

321-4172

DECAL

- operator's manual, late production

1шт.

Part of Decal Kit, P/N R41242

1шт.

9

R38893

CASE

- operator's manual, late production

1шт.

10

151-522

RIVET,Pop, 3/16" x .575"

- operator's manual case, late production

3шт.

11

321-3279

DECAL

- treads, late production

6шт.

12

321-3116

DECAL

- treads, late production

4шт.

13

D52031

SUPPORT - use with A59450 emblem only, late production

1шт.

14

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

- hex, 3/8" - 16 NC x 1", late production

2шт.

A59450

WARNING SIGN

EMBLEM- slow moving vehicle, used only on models without ROPS, late production, Includes: Ref. 15 and 16

1шт.

15

NSS

NOT SOLD SEPARAT

PLATE - emblem, late production

1шт.

16

321-1751

DECAL

- emblem, late production

1шт.

17

173-96

SCREW,Sl Rnd Hd, #10 - 24 x 7/16"

- flat, no. 10 - 24 NC x 7/16", late production

2шт.

18

92-3

LOCK WASHER,#10

WASHER, LOCK, , Late production #10

2шт.

19

129-7

NUT,Hex, #10 - 24

- HEX, NO. 10-24 NC, late production

2шт.

D52581

TRAFFIC SIGN

EMBLEM - slow moving vehicle, used on ROPS models, bolts onto rear guard screen, late production, Includes: Ref. 21 and 22

1шт.

21

NSS

NOT SOLD SEPARAT

PLATE - emblem, late production

1шт.

22

321-1751

DECAL

- emblem, late production

1шт.

23

182-203

SCREW

- machine, slotted, 1/4" - 20 NC x 5/8", late production

2шт.

24

92-4

LOCK WASHER,1/4"

WASHER, LOCK, , Late production 1/4"

2шт.

25

25-104

NUT,1/4"-20, G5

Late production 1/4"-20, G5

2шт.

26

321-4614

TAG

- Do Not Operate, late production

1шт.

R41242

DECAL

KIT - decal, late production, Includes: Ref. 5 - 8 and Ref. 1 - 42 on Figure 434

1шт.
