Запчасти Case 310G (144) - LOADER AND DOZER PRIMARY HYDRAULICS (05) - UPPERSTRUCTURE CHASSIS

1

218-449

HYD CONNECTOR,1-5/8" - 12 Male JIC x 1-1/4" - 11-1/2 Male NPTF

CONNECTOR - straight, male

1шт.

2

D40273

TUBE - reservoir to pump (Rear section)

1шт.

3

37753

BUSHING

BRACKET - tube clamp

1шт.

4

13-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5, Full Thd

1шт.

5

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

6

25-1010

NUT,5/8"-11, G5

1шт.

7

D25156

CLAMP

- tube

1шт.

8

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

9

92-5

LOCK WASHER,5/16"

1шт.

10

9635082

NUT,5/16" - 18, Gr 5

- hex. (5/16" - 18 NC)

1шт.

11

R13911

HOSE,31.80 mm ID x 101.60 mm ID, SAE 100R3

- reservoir to pump 31.80 mm ID x 101.60 mm ID, SAE 100R3

1шт.

12

214-258

HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm

2шт.

13

D40275

STEM - hose

1шт.

14

218-5011

O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro

SEAL - "O" ring

1шт.

15

D41390

PUMP

- hydraulic, 19-1/2" G.P.M. at 1850 R.P.M. (Parts list Figure 244)

1шт.

15

DR41390

REMAN-HYD PUMP

Remanufactured, Pump, Hydraulic

1шт.

15

DC41390

CORE-HYDRAULIC PUMP

Return Part Number, Pump, Hydraulic

1шт.

15

87644746R

REMAN-HYD PUMP

310G, (S/N 3039619 & After), Reman For New P/N D41390 & 87644746

1шт.

15

87644746C

CORE-HYDRAULIC PUMP

Return Part Number

1шт.

16

13-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd

2шт.

17

92-8

LOCK WASHER,1/2"

2шт.

18

D140524

FLEXIBLE COUPLING,13T

HUB - pump drive coupling

1шт.

19

G36905

BLOCK

AND BUSHING

4шт.

20

13-724

BOLT,Hex, 7/16" - 14 x 1-1/2", Gr 5

Hex, 7/16"-14 x 1 1/2, G5

4шт.

21

92-7

LOCK WASHER,7/16"

4шт.

22

A30013

WASHER,11.51mm ID x 19.05mm OD x 1.59mm Thk

- special

4шт.

23

218-5140

45 ELBOW,45 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB

- 45 degrees, adjustable

1шт.

24

218-5010

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

SEAL - "O" ring

1шт.

25

D36900

HOSE - pump to control valve (Front) 18-1/2" long

1шт.

26

D33284

TUBE - pump to control valve

1шт.

27

D27673

BRACKET - tube clamp

1шт.

28

13-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5, Full Thd

1шт.

29

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

30

25-1010

NUT,5/8"-11, G5

1шт.

31

D25157

CLAMP - tube

1шт.

32

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

33

92-5

LOCK WASHER,5/16"

1шт.

34

9635082

NUT,5/16" - 18, Gr 5

- hex. (5/16" - 18 NC)

1шт.

35

R15257

CLAMP

- tube

2шт.

36

13-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

1шт.

37

D35217

BUSHING

SPACER - tube clamp

1шт.

38

92-5

LOCK WASHER,5/16"

1шт.

39

9635082

NUT,5/16" - 18, Gr 5

- hex. (5/16" - 18 NC)

1шт.

40

D33289

HOSE ASSY.

HOSE - pump to control valve (Rear) 36" long

1шт.

41

D40471

CLAMP

- hose

2шт.

42

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

1шт.

43

92-6

LOCK WASHER,3/8"

1шт.

44

25-106

NUT,3/8"-16, G5

- hex. (3/8" - 16 NC)

1шт.

45

218-5124

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

Adjustable 90º, 1 5/16"-12, 37º x 1 1/16"-12, O-Ring

1шт.

46

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

SEAL - "O" ring

1шт.

47

REF

INSTRUCTION

VALVE - hydraulic control (See Figures 212, 214 and 216 for proper valve)

1шт.

48

D28890

CONNECTOR, ELEC

CONNECTOR - straight, male

1шт.

49

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

SEAL - "O" ring

1шт.

50

D25183

ELBOW

- 90 degrees, adjustable

1шт.

51

D33888

HOSE - control vale to reservoir (39" long)

1шт.

52

D36903

TUBE - control, Serial Range: valve-reservoir

1шт.

53

218-488

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1" - 11-1/2 Male NPTF

- 90 degrees, male

1шт.

54

D43567

FILTER ASSY

- hydrualic oil (Parts list Figure 246)

1шт.

55

221-416

ELBOW,90 Degree, 1"-11 1/2, NPT

- 90 degrees, male

1шт.

56

D36898

PIPE CLAMP

RETURN TUBE AND COVER ASSEMBLY - hydraulic oil

1шт.

57

36321

GASKET

- return tube and cover

1шт.

58

14-616

BOLT,Hex, 3/8" - 24 x 1", Gr 5

HHCS - 3/8" - 24 NF x 1" (Used on D44385 cowl)

6шт.

58

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

Used on D51345 cowl Hex, 3/8"-16 x 1", G5, Full Thd

6шт.

59

D32117

COPPER WASHER

WASHER, COPPER, Special

6шт.

60

R15536

VALVE

- relief, 10 to 20 P.S.I.

1шт.

61

221-1084

REDUCER,Hex, 1/4" x 1/8" NPT

BUSHING - reducing

1шт.

62

221-431

TEE

- pipe

1шт.

63

R15538

VALVE

- breather, 2 to 5 P.S.I.

1шт.

64

221-1130

PIPE,Nipple, 1/4" NPT x 7/8"

NIPPLE - pipe

1шт.
