Запчасти Case 310F (206) - SCARIFIER (05) - UPPERSTRUCTURE CHASSIS

1

37399

PUMP, FUEL INJECTION

PLATE - mounting

1шт.

2

31696

BOLT

"U" BOLT - mounting plate to final drive spacer

2шт.

3

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

4

25-1110

NUT,5/8"-18, G5

- hex. (5/8" - 18 NF)

4шт.

5

14-1024

BOLT,Hex, 5/8" - 18 x 1-1/2", Gr 5

2шт.

6

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

7

25-1110

NUT,5/8"-18, G5

- hex. (5/8" - 18 NF)

2шт.

8

D29985

LOCK

- transport safety

1шт.

9

D25951

BOLT

- special (1-1/4" - 12 NF x 3-1/4")

1шт.

10

25-1220

SLOTTED NUT,1 1/4"-12, G5

NUT - hex., slotted (1-1/4" - 12 NF)

1шт.

12

11469

SPRING

- transport safety lock

1шт.

13

CAS31375

KNOB

- transport safety lock

1шт.

14

D24650

X

FRAME - scarifier (Use 1 - D33518, 1 - D26105 and 2- R15389)

1шт.

D33518

FRAME - scarifier

1шт.

15

D32789

BUSHING,31.98mm ID x 41.27mm OD x 19.05mm L

- scarifier frame

4шт.

16

31715

PIN

- mounting, frame to mounting plate

2шт.

17

132-152

PIN

- cotter, 31715 pin (1/4" x 1-3/4")

4шт.

18

D23748

TOOTH

- scarifier

5шт.

19

D25598

TOOTH

POINT - scarifier tooth

5шт.

20

D30592

WEDGE

- retainer, scarifier tooth

5шт.

21

132-148

COTTER PIN,1/4" x 1 1/4"

Pin, Split (Cotter), , D30592 wedge 1/4" x 1 1/4"

5шт.

22

19041

WEIGHT - scarifier (Dozer - scarifier models only) See D28845

2шт.

D28845

WEIGHT - scarifier (Loader - scarifier models only) See 19041

2шт.

23

CAS19055

PIN ASSY.

PIN - scarifier weight

4шт.

24

D31185

CYLINDER - scarifier, hydraulic (See Figure 204 for breakdown)

1шт.

25

D21331

PIN - mounting, cylinder to frame (D24650 frame only)

1шт.

26

D26105

PIN ASSY.

PIN - mounting, Serial Range: cyl.-frame

1шт.

27

D26918

SNAP RING,#125, Ext

Ring, Snap, , mounting pin #125, Ext

2шт.

28

35031

PIN

- trunnion, cylinder to mounting plate

2шт.

29

219-40

LUBE NIPPLE,65 Degree Elbow, 1/8" - 27 NPTF

FITTING - grease, 67-1/2 degrees (1/8" NPT)

2шт.

30

14-816

BOLT,Hex, 1/2" - 20 x 1", Gr 5

HHCS - 1/2" - 20 NF x 1"

2-3шт.

31

193-32

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

2-3шт.

32

D23740

BUSHING

- lockhead pin

2-3шт.

33

R15389

SPACER

- piston rod (D33518 frame only)

2шт.

11

132-56

COTTER PIN,Ext Prong Sq Cut, 1/8" x 2"

Pin, Split (Cotter), , Special bolt 1/8" x 2"

1шт.
