Артикул
Название
Примечание
Количество
1
38488
HYD CONNECTOR
FENDER - L.H.
1шт.
38746
DECAL
FENDER - L.H., loaders models
1шт.
D21125
FENDER - L.H., 36" gauge tractor
1шт.
2
38489
HYD CONNECTOR
FENDER - R.H.
1шт.
38747
FENDER - R.H., loader models
1шт.
D21124
FENDER - R.H., 36" gauge tractor
1шт.
3
13-824
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd
2шт.
4
13-816
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
4шт.
5
92-8
LOCK WASHER,1/2"
6шт.
6
25-108
NUT,1/2"-13, G5
- hex. (1/2 - 13 NC)
6шт.
7
D25383
TANK - fuel
1шт.
8
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
9
13-614
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd
8шт.
10
92-6
LOCK WASHER,3/8"
10шт.
11
25-106
NUT,3/8"-16, G5
- hex. (3/8 - 16 NC)
10шт.
12
34574
BUSHING,35.09mm ID x 44.5mm OD x 76.2mm L
COVER - fuel tank drain
1шт.
13
35621
GASKET
- fuel tank drain cover
1шт.
14
14-614
SCREW,Hex, 3/8" - 24 x 7/8", Gr 5
HHCS - 3/8 - 24 NF x 7/8
4шт.
15
92-6
LOCK WASHER,3/8"
4шт.
16
221-1
DRAIN PLUG,Sq Hd, 1/8"-27 NPTF
PLUG - pipe, 1/8" NPT square head
1шт.
17
CASE10731
FILLER CAP
CAP - filler, fuel tank
1шт.
18
D21051
SEAT AND BACK
1шт.
19
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
3шт.
20
92-6
LOCK WASHER,3/8"
3шт.
21
25-106
NUT,3/8"-16, G5
- hex. (3/8 - 16 NC)
3шт.
22
49561
GROMMET,1/4" ID x 7/16" Groove Dia
- rubber (1/2")
1шт.
23
D27691
X
CUSHION - seat
1шт.
24
D27690
CUSHION - seat back
1шт.
25
D27693
ARMREST
CUSHION - arm rest
2шт.
26
13-412
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
4шт.
27
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
Выбрано товаров: 31
