Артикул
Название
Примечание
Количество
1
REF
INSTRUCTION
VALVE - control, see Fig. 204 or 206 for correct valve
1шт.
2
HYD CONNECTOR,3/4" - 16 Male JIC x 7/8" - 14 Male ORB
Fitting, straight, Incl. Ref 3 3/4"-16, 37º x 7/8"-14, O-Ring
2шт.
3
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
- fitting
1шт.
4
R39992
TUBE ASSY.
TUBE - A port
1шт.
5
R39994
TUBE ASSY.,0.5" OD
TUBE - B port
1шт.
6
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
2шт.
7
92-6
LOCK WASHER,3/8"
2шт.
8
R40031
BRACKET
- mounting tubes
1шт.
9
R40511
BAR - mounting, tubes
1шт.
10
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
- hex, 3/8" - 16 NC x 1-1/2"
4шт.
11
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
" Hex, 3/8"-16 x 3/4", G5, Full Thd
1шт.
12
R25528
CLAMP
- tubes
6шт.
13
D40236
CLAMP
- tubes
2шт.
14
D76208
SPACER
- clamp (Replaces F14143)
7шт.
15
92-6
LOCK WASHER,3/8"
8шт.
16
25-106
NUT,3/8"-16, G5
- hex, 3/8" - 16 NC
4шт.
17
35453
SPARE PART
- 22" (559 mm) long
2шт.
18
R39990
TUBE,0.5" OD
- outer, A port
1шт.
19
R39988
TUBE,0.5" OD
- inner, B port
1шт.
20
R39980
TUBE,0.5" OD
- outer, A port
1шт.
21
R39982
TUBE,0.5" OD
- inner, B port
1шт.
22
218-1255
BHD LOCK NUT,Blkhd, 3/4"-16
NUT, LOCK, Blkhd, 3/4"-16
2шт.
23
D35268
SHIM,1/32" Thk
Washer, Special 1/32" Thk
2шт.
24
R29758
FITTING
ELBOW - 90 degree, bulkhead
2шт.
25
R34008
GUARD
- fittings
1шт.
26
13-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd
2шт.
27
92-8
LOCK WASHER,1/2"
2шт.
28
195-33
WASHER,1/2"
- flat, 1/2"
2шт.
29
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
3шт.
Выбрано товаров: 29
