Запчасти Case 450 (102) - TRANSMISSION HIGH AND LOW CLUTCH SHAFTS (03) - TRANSMISSION

1

A54108

SHAFT

ASSY. - forward and reverse clutch and constant running PTO., Includes: Ref. 1A and 1B

1шт.

1a

211-7

BALL,1/4" Dia

Steel (Not shown)

1шт.

1b

211-11

BALL,3/8" Dia

Steel (Not shown)

1шт.

2

138-68

LOCK PIN,5/32" x 7/16", Slotted

2шт.

3

A51841

RING

Seal, clutch shaft oil collector

3шт.

4

A30076

ROLLER BEARING,1.625" ID x 0.963"

CONE

1шт.

5

G15202

CUP

1шт.

6

R20786

RING

Snap, front bearing retaining

1шт.

7

REF

INSTRUCTION

CLUTCH ASSEMBLY - forward and reverse, parts list Figure 109A

2шт.

8

A50046

RING

Snap, clutch retaining

2шт.

9

A50048

ROLLER BEARING,40mm ID x 21.69mm W

CONE, clutch shaft, rear

1шт.

10

A27138

BEARING CUP,85 mm OD x 17.462 mm

Bearing, clutch shaft, rear

1шт.

11

40027

BALL BEARING,49.99mm ID x 80mm OD x 16mm W

ASSEMBLY - clutch

4шт.

12

A50293

SPACER

Clutch bearings

2шт.

13

A50506

GEAR

Drive, forward clutch

1шт.

14

A50034

SPACER

SPACER - drive gears

1шт.

15

A50505

GEAR WHEEL

Drive, reverse clutch

1шт.

16

A54107

OIL SEAL,38.1mm ID x 8mm Thk

Oil, PTO shaft

1шт.
