Запчасти Case 450 (200) - TRACK GUIDES, BEFORE TRACTOR SN. 3050801 (04) - UNDERCARRIAGE
№
Артикул
Название
Примечание
Количество
1
D39558
GUARD
- sprocket, outer (L.H.)
1шт.
2
D39559
GUARD
- sprocket, outer (R.H.)
1шт.
3
13-1020
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5, Full Thd
8шт.
5
D39560
BLOCK
- sprocket guard mounting
2шт.
6
13-828
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
HHCS - 1/2" - 13 NC x 1-3/4"
4шт.
7
195-33
WASHER,1/2"
- flat () 1/2"
4шт.
8
92-8
LOCK WASHER,1/2"
med. sect. 1/2"
4шт.
9
129-105
NUT,Hex, 1/2" - 13, Gr 5
(Replaces 25-108) 1/2"-13, G5
4шт.
10
D39566
GUARD
TRACK GUIDE - rear, outer (L.H.)
1шт.
11
D42782
GUARD
TRACK GUIDE - rear, inner (L.H.) 50" gauge models
1шт.
11
D50533
LOCK
TRACK GUIDE - rear, inner (L.H.) 52" gauge models
1шт.
12
D39567
GUARD
TRACK GUIDE - rear, outer (R.H.)
1шт.
13
D42781
GUARD
TRACK GUIDE - rear, inner (R.H.) 50" gauge models
1шт.
13
D50532
GUARD
TRACK GUIDE - rear, inner (R.H.) 52" gauge models
1шт.
14
D35387
GUIDE
TRACK GUIDE - center
4шт.
15
D39553
GUARD
TRACK GUIDE - front, L.H.
2шт.
16
D39554
GUARD
TRACK GUIDE - front, R.H.
2шт.
17
13-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd
32шт.
18
92-8
LOCK WASHER,1/2"
med. sect. 1/2"
32шт.
19
195-33
WASHER,1/2"
- flat () 1/2"
32шт.
20
13-1020
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5, Full Thd
2шт.
22
195-41
WASHER,5/8"
- flat () 5/8"
2шт.
23
13-8120
BOLT,Hex, 1/2" - 13 x 7-1/2", Gr 5
HHCS - 1/2" - 13 NC x 7-1/2"
10шт.
24
D35372
BUSHING
SPACER - track guide
10шт.
25
92-8
LOCK WASHER,1/2"
med. sect. 1/2"
10шт.
26
129-105
NUT,Hex, 1/2" - 13, Gr 5
(Replaces 25-108) 1/2"-13, G5
10шт.
27
D39575
GUARD
- rock, idler wheel (L.H.)
2шт.
28
D39574
GUARD
- rock, idler wheel (R.H.)
2шт.
29
13-1224
BOLT,Hex, 3/4" - 10 x 1-1/2", Gr 5
8шт.
30
D35268
SHIM,1/32" Thk
Guard 1/32" Thk
1шт.
31
D39576
GUARD
- rock, track frame, Serial Range: -3044216
2шт.
31
D48940
GUARD
- rock, track frame (Used on tractor Sn. 3044216 thru 3050801) Not illustrated
2шт.
32
13-1248
BOLT,Hex, 3/4" - 10 x 3", Gr 5
4шт.
Выбрано товаров: 35
