Запчасти Case 450 (166) - PULL HOOK, CRANKCASE, TORQUE CONVERTER, AND SEDIMENT BOWL GUARD (03) - TRANSMISSION

1

10940

HOOK

- pull, all models except Backhoe models

1шт.

2

13-828

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5

HHCS - 1/2" - 13 NC x 1-3/4"

6шт.

3

92-8

LOCK WASHER,1/2"

6шт.

4

D35159

GUARD

- crankcase, Drawbar and Dozer Models

1шт.

5

D35157

GUARD

- crankcase, Loader Models without backhoe

1шт.

6

13-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5, Full Thd

4шт.

7

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

8

195-41

WASHER,5/8"

- plain () 5/8"

4шт.

9

D35162

GUARD

- torque converter

1шт.

10

13-1040

BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5

2шт.

11

13-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 5

4шт.

12

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

6шт.

13

195-41

WASHER,5/8"

- plain () 5/8"

6шт.

14

D42811

GUARD - rear sediment bowl (Models without rear mounted equipment)

1шт.

15

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

4шт.

16

92-8

LOCK WASHER,1/2"

4шт.

17

D41579

GUARD ASSY.

GUARD - transmission, Serial Range: -3041180

1шт.

18

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

Transmission guard Hex, 1/2"-13 x 1 1/4", G5, Full Thd, Serial Range: -3041180

2шт.

19

195-33

WASHER,1/2"

- plain, transmission guard, Serial Range: -3041180

2шт.

20

195-533

WASHER,1/2", SAE

BRACKET - retaining (Replaces D41580), transmission guard, Serial Range: -3041180

2шт.
