Запчасти Case 450 (091A) - ENGINE PRE-HEATER (01) - ENGINE

D35092

SWITCH

AND KEY - electrical, Includes: Ref.#1 & 2

1шт.

1

D35092

SWITCH

- ignition

1шт.

2

D36822

KEY

- switch (Set of two)

1шт.

3

REF

INSTRUCTION

MAIN WIRING HARNESS - Fig. 80 & 84 for service

1шт.

4

A39079

SOLENOID

- manifold heater (Generator models)

1шт.

4

A57069

SOLENOID

- manifold heater (Alternator models)

1шт.

5

113-1

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

1шт.

6

113-3

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

1шт.

7

193-60

LOCK WASHER,Int Tooth, 1/4"

WASHER - med. sect. lock (1/4") Zinc plated

2шт.

8

86637933

JAM NUT,5/16" - 24, Gr 5

2шт.

9

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

10

193-1000

NUT,Keps, w/LW,#10-32

- keps (No. 10) Zinc plated

2шт.

11

D51990

CABLE PULLING GRIP

CABLE - starter to solenoid (When stock is exhausted, use R29755 cable)

1шт.

12

87016560

JAM NUT,Jam, 3/8"-16, G5

1шт.

13

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

14

193-1002

NUT,Keps, #8 - 32, w/ Ext Tooth LW

- keps (No. 8 - 32 NC) Zinc plated

1шт.

15

D51989

WIRE HARNESS

WIRE - solenoid to heater plug

1шт.

16

A37775

HEATER

PLUG - heater, manifold, Includes: Ref.# 17 & 18

1шт.

17

A20916

MANIFOLD GASKET

GASKET - heater plug

1шт.

18

7770

NUT,Hex, 1/4 - 20, Cl 5

- terminal (1/4" - 10 NC)

1шт.
