Запчасти Case 450 (290) - TWO SPOOL VALVES AND LEVERS, ALL VALVES HAVE PART NUMBER ON VALVE IDENTIFICATION PLATE (07) - HYDRAULIC SYSTEM

1

D35214

VALVE - two spool (Used on Power Angling Dozer and Drawbar Models) Parts list Fig. 300 (Use D45038 valve for service)

1шт.

D45038

VALVE

- two spool (Used on Power Angling Dozer and Drawbar Models) Parts list Fig. 302

1шт.

R30043

VALVE

- two spool (Used on Power Angling Dozer and Drawbar Models) Parts list Fig. 303A

1шт.

D35212

VALVE

- two spool (Used on Loader Models without return-to-dig feature) Parts list Fig. 300 (Use D45039 valve for service)

1шт.

D45039

VALVE

- two spool (Used on Loader Models without return-to-dig feature) Parts list Fig. 302

1шт.

D44215

NO LONGER SERVICED

VALVE - two spool (Used on Return-to-Dig Loader Models before tractor Sn. 3048572) Parts list Fig. 304 (Used R24134 valve and R24133 harness), Serial Range: -3048572

1шт.

R24134

VALVE

- two spool (Used on Return-to-Dig Loader Models tractor Sn. 3048572 and after) Parts list Fig. 306, Start Serial: 3048572

1шт.

2

13-668

BOLT,Hex, 3/8" - 16 x 4-1/4", Gr 5

HHCS - 3/8" - 16 NC x 4-1/4"

4шт.

3

92-6

LOCK WASHER,3/8"

WASHER - med. sect. lock 3/8"

4шт.

4

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, (Replaces 25-106) 3/8"-16, G5

4шт.

5

D45388

PIN

- retaining, pivot lever

1шт.

6

138-61

LOCK PIN,1/8" x 1", Slotted

PIN, 1/8" x 1", Slotted

1шт.

7

D43451

LEVER

- pivot

1шт.

8

D43453

LINK

- long, use with all valves

2шт.

9

D43450

LEVER

- valve control

1шт.

10

D43620

COLLAR

- control lever

1шт.

11

83-54

SET SCREW,Hex Soc, 5/16"-18 x 1/4", Cup Pt

1шт.

12

D38662

RING

BUSHING - spacer

2шт.

13

D37550

KNOB

- control lever

1шт.

14

129-123

NUT,3/8"-24, G5

(Replaces 25-116) 3/8"-24, G5

2шт.

15

92-6

LOCK WASHER,3/8"

WASHER - med. sect. lock 3/8"

2шт.

16

D40908

BALL JOINT

2шт.

17

D37549

STUD

BOLT - stud (3/8" - 24 NF)

1шт.

18

D37574

CRANK

LEVER - bell crank

1шт.

18a

R30508

LEVER

- bell crank

1шт.

19

A26411

WASHER

- special

1шт.

20

138-61

LOCK PIN,1/8" x 1", Slotted

PIN, 1/8" x 1", Slotted

1шт.

21

D43454

LINK

- short, all valves (D44215 valve uses 1)

1-2шт.

22

D44268

LINK

- short, use on D44215 valve

1шт.

23

D43452

PIN,12.72mm OD x 61.91mm L

- link retaining

4шт.

24

132-24

COTTER PIN,3/32" x 1/2"

PIN - cotter (3/32" x 1")

4шт.

25

132-24

COTTER PIN,3/32" x 1/2"

WASHER - spacer

1шт.

26

219-4

LUBE NIPPLE,1/8" - 27 NPTF

FITING - grease, straight (1/8" NPT) If used

2шт.
