Запчасти Case 450 (238) - LOADER RETURN TO DIG PARTS, USED BEFORE TRACTOR SN 3048572 (05) - UPPERSTRUCTURE CHASSIS

D35092

SWITCH

AND KEY - electrical, Includes: Ref.#1 & 2

1шт.

1

NSS

NOT SOLD SEPARAT

SWITCH - electrical

1шт.

2

D36822

KEY

- switch, pair

1шт.

3

D44377

ELECTRICAL WIRE

WIRE - white, electrical switch to limit switch (When stock is exhausted, use D46644 harness)

1шт.

D46644

HARNESS

CABLE - wiring harness

1шт.

4

D44417

LOOM

- wire (Used with D44377 wire only)

1шт.

5

49838

CLAMP

- wire (Used on D44377 wire and D44417 loom only)

2шт.

515-2348

CLAMP,4.8mm ID, 10.3mm Bolt Hole, P Type

- wire (Used on D46644 cable)

2шт.

6

13-610

BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd

1шт.

7

92-6

LOCK WASHER,3/8"

WASHER - lock, 3/8"

1шт.

8

NLS

NO LONGER SERVICED

1шт.

9

D40921

SWITCH

- limit

1шт.

10

169-144

SCREW,Sl Fil Hd, #6 - 32 x 1 1/4"

- machine, fillister head (#6 - 32 NC x 1-1/4")

2шт.

11

D40924

SHIM

SPACER - switch

1шт.

12

193-89

LOCK WASHER,Ext-Int Tooth, #6

WASHER, LOCK, Ext-Int Tooth, #6

2шт.

13

129-15

NUT,#6-32

2шт.

14

D49884

BOX - limit switch mounting

1шт.

15

D40922

COVER

- limit switch

1шт.

16

173-224

SCREW,Sl Rnd Hd, #8 - 32 x 1/4"

- machine, round head (#8 - 32 NC x 1/4")

2шт.

17

193-90

LOCK WASHER,Ext, #8

WASHER, LOCK, Ext, #8

2шт.

18

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP - tube, worm screw type

1шт.

19

D44214

SUPPORT TUBE

TUBE - rod support

1шт.

20

D44211

ROD

- limit switch

1шт.

21

L13698

LINK - outer, R.H.

1шт.

22

195-33

WASHER,1/2"

- plain () 1/2"

1шт.

23

132-48

COTTER PIN,1/8" x 1"

PIN - cotter (3-1/4" x 3/32")

1шт.

24

D44212

BRACKET - limit switch box

1шт.

25

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

26

92-6

LOCK WASHER,3/8"

WASHER - lock, 3/8"

2шт.

27

13-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

1шт.

28

92-6

LOCK WASHER,3/8"

WASHER - lock, 3/8"

1шт.

29

195-25

WASHER,3/8"

- plain () 3/8"

1шт.

30

D44208

SLEEVE

- tube

1шт.

31

D44378

LOOM

- wire (Used with D44377 wire only)

1шт.

32

49838

CLAMP

- wire (Used with D44377 wire and D44378 loom)

1шт.

515-23127

CLAMP,1/2", Insul, 3/8" Bolt

- wire (Used on D46644 cable)

1шт.

33

13-610

BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd

1шт.

34

92-6

LOCK WASHER,3/8"

WASHER - lock, 3/8"

1шт.

35

49838

CLAMP

- (Used with D44377 wire and D44378 loom)

1шт.

515-23127

CLAMP,1/2", Insul, 3/8" Bolt

- wire (Used on D46644 cable)

1шт.

36

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

1шт.

37

92-6

LOCK WASHER,3/8"

WASHER - lock, 3/8"

1шт.

38

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, (Replaces 25-106) 3/8"-16, G5

1шт.

39

D44376

ELECTRICAL WIRE

WIRE - red, limit switch to acutator switch (When stock is exhausted, use D46644 harness)

1шт.

D46644

HARNESS

CABLE - wiring harness

1шт.

40

D40921

SWITCH

- actuator

1шт.

41

169-144

SCREW,Sl Fil Hd, #6 - 32 x 1 1/4"

- machine, fillister head (#6 - 32 NC x 1-1/4")

2шт.

42

193-89

LOCK WASHER,Ext-Int Tooth, #6

WASHER, LOCK, Ext-Int Tooth, #6

4шт.

43

129-15

NUT,#6-32

2шт.

44

D44404

GUARD ASSY.

LOOM - wire

1шт.

45

49838

CLAMP

- loom

1шт.

46

REF

INSTRUCTION

VALVE - loader, see Figs. 290 - 296 for proper valves

1шт.
