Запчасти Case 420C (194) - 900 LB. REAR COUNTERWEIGHT (WITH WINCH) (05) - UPPERSTRUCTURE CHASSIS

1

32105

COUNTERWEIGHT - rear, 900 lb.

1шт.

2

13-1680

CAPSCREW,Hex, 1" - 8 x 5", Gr 5

BOLT, Hex, 1"-8 x 5", G5

4шт.

3

230-41116

NUT,1"-8, GA

NUT - lock (1" - 8 NC)

4шт.

4

D26890

ROD - support, R.H.

1шт.

5

D26889

ROD - support, L.H.

1шт.

6

195-41

WASHER,5/8"

2шт.

7

230-4117

LOCK NUT,7/16"-14, GA

NUT - lock (5/8" - 11 NC)

2шт.

8

95-10

WASHER,5/8"

- standard wrot (11-16" I.D. x 1-3/4" O.D. x 9/64" thick)

2шт.

9

132-91

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

2шт.

10

D26910

ARM - counterweight support, R.H. (Original equipment) when stock is exhausted, order 1 - D29744, 2 - 13-1248, and 2 - 131-357

1шт.

D29744

ARM - counterweight support, R.H. (Replacement) See D26910

1шт.

11

D26911

ARM - counterweight support, L.H. (Original equipment) when stock is exhausted, order 1 - D29743, 2 - 13-1248, and 2 - 131-357

1шт.

D29743

ARM - counterweight support, L.H. (Replacement) See D26911

1шт.

12

13-1248

BOLT,Hex, 3/4" - 10 x 3", Gr 5

2шт.

13

D21262

WASHER

SPACER

2шт.

14

230-41112

LOCK NUT,3/4"-10, GA

NUT - lock (3/4" - 10 NC)

2шт.

15

13-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5

HHCS - 1/2" - 13 NC x 2-1/2"

2шт.

16

W8199S

SPACER - 21/32" I.D x 2-1/8" O.D. x 9/64" thick)

2шт.

17

131-354

LOCK NUT,1/2"-13, GA

NUT - lock (1/2" - 13 NC)

2шт.

18

13-1040

BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5

(D26910 and D26911 support arms) See 13-1248 Hex, 5/8"-11 x 2 1/2", G5

4шт.

13-1248

BOLT,Hex, 3/4" - 10 x 3", Gr 5

(D29743 and D29744 support arms) See 13-1040 Hex, 3/4"-10 x 3", G5

4шт.

19

W8199S

SPACER - 21/32" I.D. x 2-1/8" O.D. x 9/64" thick (Lower 13-1040 cap screws) See O907B

2шт.

O907B

SPACER - 25/32" I.D. x 1-7/16" O.D. x 9/64" thick (Lower 13-1248 cap screws) See W8199S

4шт.

20

230-4117

LOCK NUT,7/16"-14, GA

NUT - lock (5/8" - 11 NC) 13-1040 cap screws

4шт.

230-41112

LOCK NUT,3/4"-10, GA

NUT - lock (3/4" - 10 NC) 13-1248 cap screws

4шт.
