Артикул
Название
Примечание
Количество
1
51200025
SHAFT
- axle, final drive, 48" gauge tractor (Standard) (13-3/16")
2шт.
32635
SHAFT - axle, final drive, 36" gauge tractor (7-9/32")
2шт.
11830-420
SHAFT - axle, final drive, 42" gauge tractor (10-3/32")
2шт.
11830-600
SHAFT - axle, final drive, 60" gauge tractor (19-3/16")
2шт.
D20362
SHAFT - axle, final drive, 68" gauge tractor (23-3/16")
2шт.
11830-720
SHAFT - axle, final drive, 72" gauge tractor (25-3/16")
2шт.
2
51200026
COUPLING
- final drive, 42" gauge tractor and wider
2шт.
32634
COUPLING
- final drive, 36" gauge tractor
2шт.
3
11817
RIVET
HOUSING - final drive, L.H. inner
1шт.
11816
RIVET
HOUSING - final drive, R.H. inner
1шт.
4
D24658
HOUSING
- final drive, outer
2шт.
5
13-728
BOLT,Hex, 7/16" - 14 x 1-3/4", Gr 5
18шт.
6
13-740
BOLT,Hex, 7/16" - 14 x 2-1/2", Gr 5
10шт.
7
92-7
LOCK WASHER,7/16"
28шт.
8
25-107
NUT,7/16"-14, G5
- hex. (7/16 - 14NC)
28шт.
9
D24688
BOLT
BOLT - body fit (1/2 - 13NC x 2-1/8)
6шт.
10
92-8
LOCK WASHER,1/2"
6шт.
11
25-108
NUT,1/2"-13, G5
- hex. (1/2 - 13NC)
6шт.
12
40002
BALL BEARING
- final drive pinion
4шт.
13
51200027
SHAFT
PINION - final drive
2шт.
14
40003
BEARING
- final driveshaft, inner
2шт.
15
CAS11833
GEAR WHEEL
GEAR - final drive
2шт.
16
CAS11853
SHAFT
- final drive
2шт.
17
40039
HINGE
BEARING - final driveshaft, outer
2шт.
18
40610
TUBE NUT
SEAL - oil, final driveshaft
2шт.
19
51200024
SPACER
- final driveshaft
2шт.
20
CAS11828
GASKET
- seal retainer
2шт.
21
11827
RETAINER
- seal, final driveshaft
2шт.
22
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
12шт.
23
92-6
LOCK WASHER,3/8"
12шт.
24
D21396
PLUG, DRAIN
PLUG - pipe, magnetic, 1/2NPT ctsk. hd.
4шт.
25
R29874
STUD
- mounting, final drive, 42" gauge and wider tractor
16шт.
46509
STUD - mounting, final drive, 36" gauge tractor
16шт.
26
231-46110
LOCK NUT,5/8"-18, GB
NUT - lock (5/8 - 18NF), 42" gauge and wider tractors
16шт.
Выбрано товаров: 35
