Запчасти Case 400 (250[1]) - (USED FROM SERIAL #3000502) (05) - UPPERSTRUCTURE CHASSIS

1

37399

PUMP, FUEL INJECTION

PLATE - mounting

1шт.

2

R53121

BOLT

"U" BOLT - mounting plate to final drive spacer tubes

2шт.

3

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

4

425-1110

NUT,5/8"-18, G5

4шт.

5

414-1024

BOLT,Hex, 5/8" - 18 x 1-1/2", Gr 5

2шт.

6

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

7

425-1110

NUT,5/8"-18, G5

2шт.

8

37398

FRAME - scarifier

1шт.

9

31715

PIN

- mounting, frame to mounting plate

2шт.

10

432-1628

COTTER PIN,1/4" x 1 3/4"

Pin, Split (Cotter), 1/4" x 1 3/4"

4шт.

11

31752

LINE

TOOTH - scarifier

5шт.

12

31714

ROD - holding, scarifier tooth

1шт.

13

132-348

COTTER PIN,1/4" x 1 1/4"

Pin, Split (Cotter), 1/4" x 1 1/4"

2шт.

14

D27696

CYLINDER - hydraulic, scarifier (See figure 258 for breakdown)

1шт.

15

35031

PIN

- trunnion, scarifier cylinder

2шт.

16

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

NIPPLE, LUBE, , NPT (Lincoln #5000) 1/8"-27 x .66 lg

2шт.

17

414-816

BOLT,Hex, 1/2" - 20 x 1", Gr 5

HHCS - 1/2 - 20 NF x 1

2шт.

18

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

395-11053

WASHER,0.53" ID x 1.06" OD x 0.1" Thk

- flat (17/32" I.D. x 1-1/16" O.D. x 7/64" thick) Not shown

2шт.

19

D21331

PIN - mounting, Serial Range: cylinder-frame

1шт.

20

414-816

BOLT,Hex, 1/2" - 20 x 1", Gr 5

HHCS - 1/2 - 20 NF x 1

1шт.

21

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

395-11053

WASHER,0.53" ID x 1.06" OD x 0.1" Thk

- flat (17/32" I.D. x 1-1/16" O.D. x 7/64" thick) Not shown

1шт.

22

19041

WEIGHT - scarifier

2шт.

23

CAS19055

PIN ASSY.

PIN - mounting, scarifier weight

4шт.
