Запчасти Case 400 (022) - CARBURETOR AND LINKAGE, (USED ON MODELS WITHOUT A TORQUE CONVERTER) (02) - FUEL SYSTEM

1

34005

WINDSHIELD WIPER

CARBURETOR - gasoline (Marvel Schebler #TSX-338) (See figure 24 for breakdown)

1шт.

2

O562AB

X

GASKET -, Serial Range: manifold-carburetor

1шт.

3

10375

STUD - carburetor to manifold (5/16 - 18 NC x 1-5/16)

2шт.

4

48525

X

WASHER - Shakeproof lock, internal tooth (5/16)

2шт.

5

47861

KNOB

NUT - hex. (5/16 - 18 NC)

2шт.

6

10031

BALL JOINT - control rod to carburetor lever

1шт.

7

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

8

425-114

NUT,1/4"-28, G5

1шт.

9

10127

ROD ASS'Y - control, Serial Range: carburetor-governor

1шт.

10

11057

WASHER - plain (5/16)

2шт.

11

48525

X

WASHER - Shakeproof lock, internal tooth (5/16)

1шт.

12

10029

SCREW - yoke end, control, Serial Range: rod-governor

1шт.
