Запчасти Case 400 (270) - BACKHOE PRIMARY HYDRAULIC SYSTEM, (USED UP TO SERIAL (07) - HYDRAULIC SYSTEM
№
Артикул
Название
Примечание
Количество
31-1393
HYD CONNECTOR,1 5/16"-12, 37 Degree x 3/4"-14, NPTF
CONNECTOR - male (1 JIC x 3/4 NPT)
1шт.
36702
TUBE
- low pressure line, reservoir to pump (Rear section) (400 diesel models only)
1шт.
D20098
TUBE - low pressure line, reservoir to pump (Rear section) (400 gas models only)
1шт.
35057
HOSE - low pressure line, reservoir to pump (Center section)
1шт.
36710
TUBE - low pressure line, reservoir to pump (Front section) (400 diesel models only)
1шт.
35063
TUBE - low pressure line, reservoir to pump (Front section) (500 diesel models only, used up to serial #3000015; used on all gas models)
1шт.
35744
TUBE - low pressure line, reservoir to pump (Front section) (500 models only, from serial #3000015)
1шт.
218-488
ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1" - 11-1/2 Male NPTF
- 90 degree male (1 JIC x 1 NPT) (400 diesel models only)
1шт.
218-448
HYD CONNECTOR,1-5/16" - 12 Male JIC x 1" - 11-1/2 Male NPTF
CONNECTOR - male (1 JIC x 1 NPT) (500 diesel models only, used up to serial #3000015; used on all gas models)
1шт.
218-538
ELBOW,45 Degree, 1 5/16"-12, 37 Degree x 1"-11 1/2, NPTF
- 45 degree male (1 JIC x 1 NPT) (500 diesel models only, from serial #3000015)
1шт.
35738
DRAWBAR
PUMP - hydraulic (See page 192 for breakdown) (Use 74838)
1шт.
74838
PUMP - hydraulic (See page 194 for breakdown)
1шт.
46513
ROD
STUD - mounting, hydraulic pump
6шт.
230-4616
LOCK NUT,3/8"-24, GA
NUT - lock (3/8 - 24 NF)
6шт.
R13926
COUPLING
- female, pump
1шт.
413-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
- 5/16 - 18 NC x 3/4
4шт.
92-5
LOCK WASHER,5/16"
4шт.
R13925
COUPLING
- male, pump
1шт.
83-58
SET SCREW,Hex Soc, 5/16"-18 x 1/2"
SCREW - set (5/16 - 18 NC x 1/2)
1шт.
221-218
PIPE,Nipple, 3/4" NPT x 3 1/2"
NIPPLE - pipe, high pressure line (Pump to elbow) (3/4 NPT x 3-1/2") (400 diesel models only)
1шт.
221-1378
ELBOW,90º, 3/4" NPT
- 90 degree pipe, high pressure line (Pipe nipple to hose) (3/4 NPT) (400 diesel models only)
1шт.
218-536
ELBOW,45 Degree, 1 1/1"6-12, 37 Degree x 3/4"-14, NPTF
- 45 degree male, high pressure line (Pump to tube) (3/4 JIC x 3/4 NPT) (500 diesel models only; also used on all gas models)
1шт.
36706
RIGID TUBE
HOSE - high pressure line, pump to diversion valve (Front section) (400 diesel models only)
1шт.
35059
THRUST WASHER
TUBE - high pressure line, pump to diversion valve (Front section) (500 diesel models only, used up to serial #3000015; used on all gas models)
1шт.
35742
CHANNEL
TUBE - high pressure line, pump to diversion valve (Front section) (500 diesel models only, serial #3000015 and after; used on all gas models)
1шт.
35055
PISTON
HOSE - high pressure line, pump to diversion valve (Center section) (500 diesel models only; used on all gas models)
1шт.
36704
LEVER
TUBE - high pressure line, pump to diversion valve (Rear section) (400 diesel models only)
1шт.
35065
DOOR SEAL
TUBE - high pressure line, pump to diversion valve (Rear section) (500 diesel models only; used on all gas models)
1шт.
218-486
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 3/4" - 14 Male NPTF
- 90 degree male, high pressure line (At diversion valve) (3/4 JIC x 3/4 NPT)
1шт.
34259
SHIM,.007" Thk
PLATE - base, front tube clamp (Rear pressure line section) (500 models only)
1шт.
49789
CLAMP
- tube, rear pressure line section (500 models only)
1шт.
414-516
BOLT,Hex, 5/16" - 24 x 1", Gr 5
HHCS - 5/16 - 24 NF x 1
1шт.
92-5
LOCK WASHER,5/16"
1шт.
35269
BRACKET - rear tube clamp, rear pressure line section (500 models only)
1шт.
49789
CLAMP
- tube, rear pressure line section (500 models only)
1шт.
414-416
BOLT,Hex, 1/4" - 28 x 1", Gr 5
HHCS - 1/4 - 24 NF x 1
1шт.
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
425-114
NUT,1/4"-28, G5
1шт.
34909
BRACKET - mounting, diversion valve
1шт.
414-612
BOLT,Hex, 3/8" - 24 x 3/4", Gr 5
2шт.
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
129-123
NUT,3/8"-24, G5
2шт.
16960
VALVE - diversion
1шт.
114-226
BOLT,Hex, 3/8" - 24 x 3-1/2", Gr 5
HHCS - 3/8 - 24 NF x 3-1/2
2шт.
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
129-123
NUT,3/8"-24, G5
2шт.
213-4
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
END - yoke
1шт.
141-54
CLEVIS PIN,3/8" x 1 1/16"
1шт.
432-612
COTTER PIN,3/32" x 3/4"
PIN , SPLIT (COTTER), 3/32" x 3/4"
1шт.
129-123
NUT,3/8"-24, G5
1шт.
32255
SPARE PART
ROD - control, diversion valve
1шт.
376959R2
KNOB
- control rod
1шт.
36708
CLAMP
TUBE - diversion valve to quick disconnect, front section (400 diesel models only)
1шт.
35152
TACHOGRAPH
TUBE - diversion valve to quick disconnect, front section (500 diesel models only; used on all gas models)
1шт.
218-446
HYD CONNECTOR,1-1/16" - 12 Male JIC x 3/4" - 14 Male NPTF
CONNECTOR - male (3/4 JIC x 3/4 NPT)
1шт.
36042
BRACKET
- tube clamp
1шт.
114-101
BOLT,Hex, 5/16" - 24 x 7/8", Gr 5, Full Thd
1шт.
92-5
LOCK WASHER,5/16"
1шт.
515-22190
CLAMP,3/4", Insul, 5/16" Bolt
Tube 3/4", Insul, 5/16" Bolt
1шт.
414-512
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
1шт.
92-5
LOCK WASHER,5/16"
1шт.
35150
TUBE - diversion valve to quick disconnect, center section
1шт.
33422
BRACKET - tube clamp
1шт.
49789
CLAMP
- tube
1шт.
414-512
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
1шт.
92-5
LOCK WASHER,5/16"
1шт.
NLS
NO LONGER SERVICED
HOSE - diversion valve to quick disconnect, rear section
1шт.
35146
QUICK DISCONNECT ASS'Y - complete
1шт.
36262
DISCONNECT - quick, male half
1шт.
36263
DISCONNECT - quick, female half
1шт.
NLS
NO LONGER SERVICED
HOSE - quick disconnect to reservoir, rear section (Used on all models up to serial #3003139)
1шт.
35131
TUBE - quick disconnect to reservoir, rear section (400 models only, from serial #3003139)
1шт.
35079
STUB AXLE/STEERING S
TUBE - quick disconnect to reservoir, rear center section (Used on all 500 models up to serial #3003139)
1шт.
38687
SCREW
TUBE - quick disconnect to reservoir, rear center section (Used on all 400 models from serial #3003139)
1шт.
33422
BRACKET - tube clamp
1шт.
49789
CLAMP
- tube
1шт.
414-512
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
1шт.
92-5
LOCK WASHER,5/16"
1шт.
35131
TUBE - quick disconnect to reservoir, front center section
1шт.
35189
HOSE - quick disconnect to reservoir, front section
1шт.
35261
TUBE - center section of diversion valve to quick disconnect line to relief valve, oil filter (500 models only, up to serial #3003139)
1шт.
218-458
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1/2" - 14 Male NPTF
CONNECTOR - male (3/4 JIC x 1/2 NPT), relief valve and oil filter (500 models only, up to serial #3003139)
1шт.
33959
PIPE FITTING
VALVE - relief (See page 288 for breakdown) Use D24452, oil filter (500 models only, up to serial #3003139)
1шт.
D24452
VALVE
- relief (See page 288 for breakdown), oil filter (500 models only, up to serial #3003139)
1шт.
33958
ELBOW - lateral, relief valve and oil filter (500 models only, up to serial #3003139)
1шт.
35168
TUBE - lateral elbow to rear center section of quick disconnect to reservoir line, relief valve and oil filter (500 models only, up to serial #3003139)
1шт.
221-330
COUPLING - female pipe (3/4 NPT) (Lateral elbow to pipe nipple), relief valve and oil filter (500 models only, up to serial #3003139)
1шт.
60300012
PIPE
NIPPLE - close pipe (3/4 NPT x 1-3/8") (Pipe coupling to torque converter oil filter rear port), relief valve and oil filter (500 models only, up to serial #3003139)
1шт.
35033
SCREW
FILTER - oil, relief valve (500 models only, up to serial #3003139)
1шт.
35261
TUBE - center section of diversion valve to quick disconnect line to relief valve, (400 models only, up to serial #3003139)
1шт.
218-458
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1/2" - 14 Male NPTF
CONNECTOR - male (3/4 JIC x 1/2 NPT), relief valve (400 models only, up to serial #3003139)
1шт.
NLS
NO LONGER SERVICED
VALVE - relief (See page 288 for breakdown) Use D24452, (400 models only, up to serial #3003139)
1шт.
D24452
VALVE
- relief (See page 288 for breakdown) See 33959, (400 models only, up to serial #3003139)
1шт.
218-495
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 1/2" - 14 Male NPTF
- 90 degree male (3/4 JIC x 1/2 NPT), relief valve (400 models only, up to serial #3003139)
1шт.
35168
TUBE - relief valve to rear center section of quick disconnect to reservoir line, (400 models only, up to serial #3003139)
1шт.
