Запчасти Case 550 (9-16) - SEAT AND TANK FRAME (09) - CHASSIS/ATTACHMENTS

1

R51828

SEAL, GLASS

FRAME - seat and tank

1шт.

2

26-1228

BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 8

- hex, 3/4 NC x 1-3/4 inch, grade 8, use with Loctite 242, seat and tank frame to main frame and transmission

8шт.

3

T53681

WASHER,19.84mm ID x 44.5mm OD x 5.559mm Thk

- flat, 20 x 44 x 6 mm, hardened

8шт.
