Запчасти Case 500 (12-040) - VAPORISER REPAIR KITS L.P.G. EQUIPMENT No Description

3109955R91

PACKAGE

Tartarini vaporiser, rebuild, as required

1шт.

3109942R1

DIAPHRAGM

first stage, regulator

1шт.

3109943R1

DIAPHRAGM

second stage, regulator

1шт.

3109944R1

DIAPHRAGM

water sealing

1шт.

3109952R1

PAD

valve

2шт.

3109948R1

PAD

pressure, relief valve

1шт.

3109946R1

PIPE

primary heating

1шт.

3109947R1

PIPE

secondary heating

1шт.

3109949R1

RING

sealing , heating pipe

3шт.

3109950R1

RING

sealing, high pressure, large

1шт.

3109951R1

RING

sealing, high pressure, small

1шт.

3109945R1

SEAL

low pressure, chamber o-ring, L.P.G. equipment

1шт.

3109956R91

REGULATOR

KIT Tartarini vaporiser, repair, as required

1шт.

3109942R1

DIAPHRAGM

first stage, regulator

1шт.

3109943R1

DIAPHRAGM

second stage, regulator

1шт.

3109953R1

O-RING

filter top seal, used in filter, and solenoid valve

1шт.

3109954R1

O-RING

filter bottom seal, used in filter, and solenoid valve

1шт.

3109952R1

PAD

valve

2шт.
