Запчасти Case 500 (06-006) - RADIATOR AND OIL COOLER No Description

3117070R92

SPARE PART

ATTACHMENT radiator and cooler, solder coated, as required

1шт.

3117071R92

RADIATOR

CPTE. w/cap 3064970R1

1шт.

895762H2

COWL

SHROUD fan

1шт.

3064970R91

COVER

radiator

1шт.

3067621R1

SCREW

set, 1/4 UNF

8шт.

895807H1

SPARE PART

COOLER oil CPTE. w/angle 3108792R91, four bolt 17426R1, and four washer 510570R1

1шт.

3065235R91

SPARE PART

SUPPORT oil cooler, CPTE.

1шт.

181360

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5

hex head, 3/8 UNF x 3/4

2шт.

103026

NUT,3/8"-24, G5

2шт.

103321

LOCK WASHER,3/8"

2шт.

3063674R1

GROMMET

4шт.

3063675R1

SPACER

4шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

4шт.

510579R1

WASHER

13/32 x 1-1/4 x 16 gallon

4шт.

103321

LOCK WASHER,3/8"

4шт.

3108792R91

SUPPORT

oil cooler, angle, CPTE.

1шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1

4шт.

510579R1

WASHER

13/32 x 1-1/4 x 16 gallon

4шт.
