Запчасти Case 650L (33.202.02) - BRAKE PEDAL AND FOOTREST MOUNTING (33) - BRAKES & CONTROLS

1

829-1410

NUT,M10 x 1.5, Cl 10.9

1шт.

2

NSS

NOT SOLD SEPARAT

Brake and Decelerator Pedal

1шт.

3

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

2шт.

4

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

2шт.

5

87395690

PLATE

Brake and Decelerator Pedal Cover

1шт.

6

627-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd

6шт.

7

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

6шт.

8

76046804

FOOTREST

1шт.

9

614-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd

4шт.

10

614-10050

BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8, Full Thd

Adjust for Brake Potentiometer Voltage

1шт.

11

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

4шт.
