1
J931811
TUBE,50.8 mm OD x 291.87 mm L
1шт.
2
J916438
INTAKE AIR HOSE
80 mm (3-5/32 in)
2шт.
3
214-3240
HOSE CLAMP,1-3/4" - 2-5/8", HD Worm, W/ Liner
4шт.
4
J802908
TURBOCHARGER
See Figure 02-11
1шт.
4
JR802908
REMAN-TURBOCHARGER
Remanufactured Turbocharger
1шт.
4
JC537886
CORE-TURBOCHARGER
Return Part Number
1шт.
JC592109
TURBOCHARGER
Return Part Number
1шт.
5
J919369
GASKET,0.5mm Thk
1шт.
6
J818823
STUD
4шт.
7
J818824
FLANGE NUT
M10
4шт.
8
J913759
HOSE
1шт.
9
J934064
TUBE,22.22 mm OD x 393, 131 mm L
1шт.
10
J937706
GASKET,0.79mm Thk
1шт.
11
845-8020
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
2шт.
12
J286499
HOSE
76 mm (3 in)
1шт.
13
214-1512
HOSE CLAMP,#12, 0.69" - 1.25", Type F Worm, W/ Liner
2шт.
14
J919687
HYD CONNECTOR
Incl. Ref 15
2шт.
15
238-5013
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 75 Duro
1шт.
16
222-993
GASKET,3/8 Tube, Fl, Copper
2шт.
