Запчасти Case 650 (2-42) - AIR CLEANER MOUNTING AND INTAKE PARTS (02) - ENGINE

1

A173852

FILTER ASSY

CLEANER ASSEMBLY - air, parts list Figure 2-44

1шт.

2

A149780

BAND

CLAMP - air cleaner, includes hardware

2шт.

3

121-230

SERRATED BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

4шт.

4

492-11038

LOCK WASHER,3/8"

4шт.

5

425-106

NUT,3/8"-16, Cl 5

4шт.

6

R56933

SUPPORT

BRACKET - air cleaner mounting

1шт.

7

121-230

SERRATED BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

2шт.

8

121-428

FLANGE BOLT,Hex, 1/2" - 13 x 1", Gr 8, Full Thd

BOLT, , Use with Loctite 242 Hex Flg, 1/2"-13 x 1", G8, Full Thd

1шт.

9

214-181

HOSE CLAMP,4-1/4" - 5-1/8", HD Worm

CLAMP - adj, 4-1/4 to 5-1/8 inch dia, at air cleaner

1шт.

10

R56932

INTAKE AIR HOSE,76.00 mm ID, 102 mm ID x 243.00 mm, SAE J200

- Air cleaner 76.00 mm ID, 102 mm ID x 243.00 mm, SAE J200

1шт.

11

214-179

HOSE CLAMP,3-1/4" - 4-1/8", HD Worm

CLAMP - adj, 3-1/4 to 4-1/8 inch dia, lower

1шт.

12

S241675

PROTECTOR

PAD - seal, air cleaner pipe

1шт.

A171342

PRECLEANER

ASSEMBLY - standard, Includes: Ref. 13 - 15

1шт.

13

NSS

NOT SOLD SEPARAT

BASE - precleaner

1шт.

14

277377R1

FILTER BOWL

BOWL - precleaner

1шт.

15

A42465

COVER

- bowl

1шт.
