1
2852101
FLANGE BOLT,Hex, M6 x 16mm
2шт.
2
4895107
HYD CONNECTOR,11/16"-16 x M12
Incl. Refs. 3, 4
1шт.
3
4899107
O-RING,1.8mm Thk x 10.52mm ID
1шт.
4
4899108
O-RING,0.364mm ID x 0.07mm Width
2шт.
5
4899467
GASKET
1шт.
6
4899519
CLAMP,M16, M6 Bolt
1шт.
7
4899106
HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB
Incl. Refs. 4, 11
1шт.
8
2852195
HYDRAULIC HOSE,6.4mm ID x 461mm L
Oil Supply
1шт.
9
4899058
O-RING,0.674" ID x 0.88" OD x 0.103"
2шт.
10
2856979
PIPE
PIPE, Turbo Drain, Incl. Ref. 9
1шт.
11
4899106
HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB
Replaces 4899121
1шт.
12
2852197
FLANGE NUT,M6 x 1
1шт.
13
2852100
FLANGE BOLT,Hex, M8 x 1.25 x 16mm
1шт.
14
2852101
FLANGE BOLT,Hex, M6 x 16mm
1шт.
15
2830887
BRACKET
1шт.
