Артикул
Название
Примечание
Количество
1
87397601
BRACKET, SUPPORTING
Cold Start Plate
1шт.
2
614-8040
BOLT,Hex, M8 x 1.25 x 40mm, Cl 8.8, Full Thd
3шт.
3
407962A1
SPACER,9.8mm ID x 12.9mm OD x 11mm L
3шт.
4
238-5011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro
3шт.
5
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
3шт.
6
832-10408
NUT,M8 x 1.25, Cl 8.8
3шт.
8
87414237
PLATE,25mm W x 102mm L x 10mm Thk
Spacer, 10 mm
1шт.
9
614-6035
BOLT,Hex, M6 x 1 x 35mm, Cl 8.8, Full Thd
2шт.
10
895-11006
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
14шт.
12
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
2шт.
13
829-1406
NUT,Hex, M6 x 1, Cl 10.9
4шт.
14
614-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
3шт.
15
47132002
HEATER
1шт.
16
440038A1
JUNCTION BLOCK
Fuse Block
1шт.
17
87410265
BAR
90 mm Jumper Copper Plate; Fuse To Relay
1шт.
18
87410602
FUSE,300A, Blade
300 Amp
1шт.
19
87396228
WIRE HARNESS
Controller Harness, Grid Heater Control; Attaches To Engine Harness; Incl. 87516581 Resistor and L71879 Diode
1шт.
87516581
RESISTOR,3.01kohm, 0.5W
3.01k
1шт.
L71879
DIODE ELEMENT,400V, 3A
1шт.
20
87442552
CABLE ASSY.
575 mm Wire; Relay To Grid Heater
1шт.
21
87419615
CABLE ASSY.
1250 mm Wire; Starter To Fuse Block
1шт.
22
D150521
CLAMP
1-2шт.
23
614-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
Replaces 811-6016
1шт.
24
892-11008
LOCK WASHER,8mm ID
5шт.
25
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
2шт.
26
82017872
HEATER
Grid
1шт.
28
87413162
GROUND STRAP
150 mm Ground Wire
1шт.
29
87436836
RELAY,12V, 40 Amp
Mini,12v 40A
2шт.
30
231-24409
NUT,#10-32
TRQ # 10 GRB
2шт.
31
87301687
SCREW,HWH, #10 - 32 x 1/2"
2шт.
Выбрано товаров: 33
