Артикул
Название
Примечание
Количество
1
86989674
ARMREST ASSY.
Includes (1) 87410160 Pad, (1) 86988140 Tube Support, (4) 895-15008 Washer, (4) 832-10408 Nut
2шт.
87410160
ARMREST
M8 x 16
1шт.
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
4шт.
832-10408
NUT,M8 x 1.25, Cl 8.8
4шт.
4
86988140
SUPPORT TUBE
1шт.
5
76067464
SEAL
Armrest Seal
2шт.
6
87446967
HANDLE
Adjustable Handle; Armrest, Plastic Handle; Replaces 76067236 Metal Handle Used On Some Models
2шт.
7
443798A1
PROTECTIVE COVER
Lamp Harness Cover, ROPS Post
1шт.
8
79105220
SCREW,Phillips Drive, Oval HD, M6 x 20mm
3шт.
9
79076208
WASHER
Nylon
3шт.
10
L18331
CABLE TIE,375.9mm L, Nylon, Black
CABLE STRAP
3шт.
11
86989603
PROTECTIVE COVER
Harness
1шт.
12
614-6016
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
2шт.
13
892-11006
LOCK WASHER,M6
2шт.
14
87400013
COVER
Microprocessor Control Box Cover
1шт.
15
614-6016
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
4шт.
16
892-11006
LOCK WASHER,M6
4шт.
17
87445567
PLATE
Divider Plate
2шт.
18
87446658
PLATE ASSY.
Toolbox Plate; Includes Lid
1шт.
19
356924A3
LATCH
Includes Hardware
1шт.
20
627-10020
BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd
9шт.
21
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
9шт.
Выбрано товаров: 22
