Артикул
Название
Примечание
Количество
1
103-16175
SNAP RING,#175, Ext
2шт.
2
L113522
SEAL
Use Loctite No. 271
4шт.
B17500
LOCTITE
Loctite, No. 271, 6 ml
1шт.
3
R53254
PIN,63.5mm OD x 195mm L
2шт.
4
R53353
WASHER,16.13mm ID x 22.23mm OD x 15.3mm L
4шт.
5
219-36
LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF
2шт.
6
119106A1
PIN,44.42mm OD x 260mm L
44 x 260 mm, Tilt Cylinder, Rod End
1шт.
7
360-1020
BOLT,Hex, 5/8" - 11 x 1 1/4", Gr 8
5/8 x 1-1/4; 8
8шт.
8
360-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 8
5/8 x 2; 8
4шт.
9
95-31262
WASHER,2.62" ID x 5" OD x 0.24" Thk
2-5/8 x 5 x 1/4
2шт.
10
95-81156
WASHER,2.56" ID x 4" OD x 0.11" Thk
2-9/16 x 4 x 1/8
12шт.
11
495-81092
WASHER,1-7/8" ID x 2-1/2" OD x 1/16" Thk
1-25/32 x 2-1/2 x 3/64
6шт.
12
70523
WASHER,16.67mm ID x 47.63mm OD x 6.35mm Thk
13шт.
13
119101A1
PIN,44.42mm OD x 165mm L
44 x 165 mm, Tilt Cylinder, Angle Cylinder
3шт.
14
119097A1
PIN,44.42mm OD x 130mm L
44 x 130 mm, Lift Cylinder, Angle Cylinder
4шт.
15
121166A1
BUSHING,45.26mm ID x 50.8mm OD x 12mm L
4шт.
16
121167A1
BUSHING,45.26mm ID x 50.8mm OD x 19.5mm L
8шт.
17
381001A1
FRAME ASSY
Includes 18 - 20
1шт.
117838A1
PIN
Welded To Trunnion Plate
1шт.
18
D33635
BUSHING,63.75mm ID x 76.2mm OD x 25.4mm L
2-1/2 x 3 x 1
4шт.
19
D40243
BUSHING,44.68mm ID x 57.15mm OD x 19.05mm L
1-3/4 x 2-1/4 x 3/4
2шт.
20
D43940
BUSHING,44.68mm ID x 57.15mm OD x 25.4mm L
1-3/4 x 2-1/4 x 1
1шт.
21
116211A2
CYLINDER
89 ID x 442mm strk, Lift, See Page(s) 8-35
2шт.
22
117511A2
CYLINDER
89 ID x 148 mm strk, Tilt, See Page(s) 8-37
1шт.
22
412357A1R
REMAN-HYD CYLINDER
750H, Reman for New PN 117511A2
1шт.
22
412357A1C
CORE-HYD CYLINDER
Return Number
1шт.
23
190595A2
CYLINDER
89 ID x 396 mm strk, Angle, See Page(s) 8-39
2шт.
23
84135900R
REMAN-HYD CYLINDER
Reman for new P/N 190595A2
2шт.
23
84135900C
CORE-HYD CYLINDER
Return Number
2шт.
24
181427A1
PIN
44 x 120 mm, Lift Cylinder
2шт.
25
144476A1
SHIM
If Equipped
10шт.
26
326-864
BOLT,Hex, 1/2" - 13 x 4", Gr 8
Use Loctite No. 242
4шт.
B17422
LOCTITE
Loctite, No. 242, 50 ml
1шт.
Выбрано товаров: 33
