Запчасти Case 750 (006) - ENGINE FRAME AND RELATED PARTS (01) - ENGINE

1

D30217

FRAME - engine

1шт.

2

D30221

GUARD - crankcase front

1шт.

3

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

HHCS - 1/2" - 20 NF x 1-3/4"

4шт.

4

92-8

LOCK WASHER,1/2"

4шт.

5

95-8

WASHER,1/2"

- standard wrot 1/2"

4шт.

6

R20456

GUARD - crankcase rear (When stock is exhausted, order D33946 for service)

1шт.

D33946

GUARD

- crankcase rear

1шт.

7

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

HHCS - 1/2" - 20 NF x 1-3/4"

8шт.

8

92-8

LOCK WASHER,1/2"

8шт.

9

95-8

WASHER,1/2"

- standard wrot 1/2"

8шт.

10

R20471

DOOR - rear crankcase guard

1шт.

11

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

HHCS - 1/2" - 20 NF x 1-3/4"

2шт.

12

92-8

LOCK WASHER,1/2"

2шт.

13

R19259

GUARD - torque converter

1шт.

14

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

HHCS - 1/2" - 20 NF x 1-3/4"

4шт.

15

92-8

LOCK WASHER,1/2"

4шт.

16

95-8

WASHER,1/2"

- standard wrot 1/2"

4шт.

17

D30218

GUARD - universal shaft and transmission

1шт.

18

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

HHCS - 1/2" - 20 NF x 1-3/4"

4шт.

19

92-8

LOCK WASHER,1/2"

4шт.

20

95-8

WASHER,1/2"

- standard wrot 1/2"

4шт.

21

D30223

CLAMP - pivot shaft

2шт.

22

13-1244

BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5

8шт.

23

25-1012

NUT,3/4"-10, G5

8шт.

24

D30220

RING - safety

1шт.

25

25-108

NUT,1/2"-13, G5

- hex. (1/2" - 13 NC)

4шт.

26

92-8

LOCK WASHER,1/2"

2шт.

27

13-1256

BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 5

8шт.

28

71671

PLATE ASSY.

HOOK - front, pull

1шт.

29

13-1240

BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5

4шт.

30

25-1012

NUT,3/4"-10, G5

4шт.

31

R18568

SUPPORT - engine front (Order D31628 for service)

1шт.

32

D31628

SUPPORT - engine front

1шт.

33

14-1244

BOLT,Hex, 3/4" - 16 x 2-3/4", Gr 5

HHCS - 3/4" - 16 NF x 2-3/4"

2шт.

34

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

35

25-1112

NUT,3/4"-16, G5

- hex. (3/4" - 16 NF)

2шт.

36

14-1032

BOLT,Hex, 5/8" - 18 x 2", Gr 5

1шт.

37

131-13

LOCK NUT,5/8"-18, GB

NUT - hex. (5/8" - 18 NF)

1шт.

38

D30323

SPACER - front engine mount (Used with R18568 front engine support only)

1шт.

39

14-1256

BOLT,Hex, 3/4" - 16 x 3-1/2", Gr 5

HHCS - 3/4" - 16 NF x 3-1/2"

2шт.

40

131-533

LOCK,3/4"-16

NUT - hex., lock (3/4" - 16 NF)

2шт.

41

D32934

COUNTERWEIGHT - front mounted (1000 lbs.)

1шт.

42

13-1672

BOLT,Hex, 1" - 8 x 4-1/2", Gr 5

2шт.

43

25-1016

NUT,1"-8, G5

2шт.

44

71671

PLATE ASSY.

HOOK - front, pull

1шт.

45

13-1272

BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5

4шт.

46

25-1012

NUT,3/4"-10, G5

4шт.

47

74621

WEIGHT

PLATE - mounting (Used on models not having pull hook)

1шт.

48

13-1264

BOLT,Hex, 3/4" - 10 x 4", Gr 5

4шт.

49

25-1012

NUT,3/4"-10, G5

4шт.

50

R19416

GUARD - rear

1шт.

51

14-1020

BOLT,Hex, 5/8" - 18 x 1-1/4", Gr 5

Hex, 5/8"-18 x 1 1/4

2шт.

52

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.
