Артикул
Название
Примечание
Количество
1
R58458
BRACKET
Mounting
1шт.
2
433-820
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
2шт.
3
80679
LOCK WASHER,1/20.507 CST ZND
2шт.
4
425-108
NUT,1/2" - 13, Gr 5
2шт.
5
R58225
SHAFT
Brake Pedal
1шт.
6
38-11622
LOCK PIN,1/4" x 1 3/8", Slotted
1/4" x 1 3/8", Slotted
1шт.
7
R58357
PEDAL
Brake, Right Hand, Includes: 9 - 12
1шт.
8
R58358
PEDAL
Brake, Left Hand, Includes: 9 - 12
1шт.
9
L31166
NEEDLE BEARING
2шт.
10
257941A1
SEAL
2шт.
11
L13071
BUSHING
1шт.
12
219-57
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
1/4 tpr x 3/4
1шт.
13
R58360
PEDAL
Brake, Center, Includes: 14 - 16
1шт.
14
L31166
NEEDLE BEARING
2шт.
15
257941A1
SEAL
2шт.
16
219-57
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
1/4 tpr x 3/4
1шт.
17
D35268
SHIM,1/32" Thk
1шт.
19
495-11053
WASHER,1/2", SAE
(17/32" x 1-1/16" x 3/32")
8шт.
20
432-816
COTTER PIN,1/8" x 1"
4шт.
21
R58362
FORK
2шт.
22
17-696
BOLT,Sq Hd, 3/8" - 16 x 6", Gr 2
3/8 x 6; 2
2шт.
23
R58461
LINK
Adjustable
2шт.
24
425-146
JAM NUT,3/8" - 16, Gr 5
4шт.
25
R36912
SPRING
3шт.
26
113-250
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd
Pedal Adjustment
1шт.
27
384083R2
YOKE
2шт.
28
413-518
BOLT,Hex, 5/16" - 18 x 1-1/8", Gr 5
5/16 x 1-1/8
2шт.
30
1272218C1
VALVE
See Page(s) 7-13
1шт.
31
413-660
BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5
3/8 x 3-3/4
2шт.
32
496-41041
WASHER,13/32" x 1 1/8" x .134"
2шт.
33
231-1446
NUT,3/8" - 16, Gr 5
2шт.
34
103583A1
LARGE PLATE
PLATE, LARGE , Brake Valve, Cab Models
1шт.
Выбрано товаров: 34
