Запчасти Case 850G (2-36) - CYLINDER HEAD COVER (PRIOR TO P.I.N. JJG0254015, EXCEPT FOR JJG0254005 TO JJG0254009) (01) - ENGINE

1

REF

INSTRUCTION

HEAD cylinder, see Figure 2-38 for correct cylinder head and parts list

1шт.

2

J283335

GASKET,2.32mm Thk

head, standard, Replaces: J282805

1шт.

2

J283000

GASKET

head, 1 notch, 0.25 mm thicker, Replaces: J921396

1шт.

2

J283002

GASKET

head, 2 notches, 0.50 mm thicker, Replaces: J921398

1шт.

3

J902604

COVER

ARM rocker

6шт.

4

J929795

GASKET

SEAL rocker arm cover, Replaces: J902666

6шт.

5

J910824

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

BOLT cover

6шт.

6

J907049

BOLT,Hex

hex flange, special, 8 - 1.25 x 21.25 mm

6шт.

7

J908118

BRACKET

lifting, rear

1шт.

8

854-12025

BOLT,Hvy Hex, M12 x 25mm, Cl 10.9

Heavy

2шт.

9

J903757

BRACKET

lifting, front, thermostat and housing

1шт.

10

J914409

HOUSING

thermostat

1шт.

A77736

THERMOSTAT

coolant thermostat, Replaces: A77920, and housing, Includes: Ref. 11 and 12

1шт.

11

J923331

GASKET

thermostat housing

1шт.

12

NSS

NOT SOLD SEPARAT

THERMOSTAT coolant, and housing

1шт.

13

J926972

FLANGE BOLT,Hex, M8 x 1.25 x 70mm, Cl 10.9

flange, heavy hex, 8 - 1.25 x 70 mm, thermostat and housing

2шт.

14

845-8035

BOLT,Hvy Hex, M8 x 35mm, Cl 8.8

Thermostat and housing

1шт.

15

J923387

SUPPORT

alternator mounting, Replaces: J910713, thermostat and housing

1шт.

16

845-8025

BOLT,Hex Flg, M8 x 25mm, Cl 8.8

Thermostat and housing

3шт.
