Запчасти Case 800 (022) - DIESEL ENGINE INSTALLATION, CYLINDER HEAD, CAMSHAFT, VALVES (01) - ENGINE

1

R11889

HEAD (CYLINDER)

HEAD ASS'Y - cylinder (With valves), Serial Range: (Optional-73774)

1шт.

NLS

NO LONGER SERVICED

ASS'Y - cylinder (Stripped)

1шт.

2

6744

FITTING

GUIDE KIT - valve

1шт.

3

NSS

NOT SOLD SEPARAT

GUIDE - exhaust valve stem

4шт.

4

NSS

NOT SOLD SEPARAT

GUIDE - intake valve stem

4шт.

5

71923

TUBE - push rod

8шт.

6

6749

PIN

INSERT KIT - exhaust valve seat

1шт.

7

NSS

NOT SOLD SEPARAT

INSERT - exhaust valve seat

4шт.

8

71926

BODY

ASS'Y - energy cell

4шт.

9

71917

FLEXIBLE HOSE

CAP - energy cell

4шт.

10

71919

RETAINER

- energy cell

4шт.

11

10607

PLUG

- energy cell retainer

4шт.

12

11159

STUD - 3/8-16 NC x 5-1/2 (Cylinder head cover mtg.)

1шт.

13

NLS

NO LONGER SERVICED

STUD - 3/8-16 NC x 2-1/4 (Manifold mtg.)

4шт.

14

10697

FITTING

STUD - 3/8-16 NC x 1-7/8 (Manifold mtg.)

3шт.

15

11163

STUD - 3/8-16 NC x 1-3/4 (Manifold mtg.)

2шт.

16

30395

PLUG - pipe, oil hole

1шт.

17

221-24

DRAIN PLUG,Sq Soc, 1/2"-14 NPTF

PLUG - pipe, cts'k. head, 1/2 NP

3шт.

18

10772

LOCK WASHER

PLUG - pipe, 3/4 NP

1шт.

19

30011

X

PLUG - fuse, 1/8 NP

1шт.

20

221-13

PLUG,Sq Hd, 3/8"-18

- pipe, ext. sq. hd. - 3/8 NP

1шт.

21

10771

LOCK WASHER

PLUG - pipe, 5/8 NP

2шт.

22

11140

BALL

GASKET - cylinder, Serial Range: head-c/case

1шт.

23

11147

GASKET

- valve cover to cylinder head

1шт.

24

NSS

NOT SOLD SEPARAT

COVER ASS'Y - valve (Used up to ser. #7080872)

1шт.

25

72641

COVER ASS'Y - valve (Used from ser. #7080872)

1шт.

26

11125

COTTER PIN

SPACER - valve cover

1шт.

27

30257

GASKET

- valve cover studs

3шт.

28

30438

X

NUT - hex (3/8-16 NC) (11130 & 72641 mtg.)

3шт.

29

32798

HOSE

- road draft tube (Used from ser. #7080872)

1шт.

30

214-1420

HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm

CLAMP - hose, road draft tube (Used from ser. #7080872)

2шт.

31

74743

TUBE - road draft (Used from ser. #7080872)

1шт.

32

74835

BRACKET - road draft tube (Used from ser. #7080872)

1шт.

33

NLS

NO LONGER SERVICED

CAMSHAFT

1шт.

34

R2283

BUSHING KIT - camshaft (Used from ser. #1-2-58)

1шт.

35

NSS

NOT SOLD SEPARAT

BUSHING - camshaft front

1шт.

36

NSS

NOT SOLD SEPARAT

BUSHING - camshaft center

1шт.

37

NSS

NOT SOLD SEPARAT

BUSHING - camshaft rear

1шт.

38

NLS

NO LONGER SERVICED

PLATE - camshaft thrust

1шт.

39

11588

NUT

SCREW - 3/8-16 NC x 7/8 (11587 mtg.)

2шт.

40

48526

X

WASHER - lock (11587 mtg.)

2шт.

41

71843

GASKET

GEAR - camshaft timing see parts bull. Mar. 2, 1962 (#5-62)

1шт.

42

10776

LOCK WASHER

KEY - Woodruff (Timing gear)

1шт.

43

10718

FITTING

NUT - camshaft timing gear

1шт.

44

10447

SEALING RING COLLAR

LOCK - nut

1шт.

45

6741

ELBOW

TAPPET KIT - valve

1шт.

46

NSS

NOT SOLD SEPARAT

TAPPET - valve

8шт.

47

71925

SPARE PART

ROD - valve push

8шт.

48

6732

VALVE KIT - intake

1шт.

49

NSS

NOT SOLD SEPARAT

VALVE - intake

4шт.

50

6735

VALVE

KIT - exhaust

1шт.

51

NSS

NOT SOLD SEPARAT

VALVE - exhaust

4шт.

52

6737

SPRING KIT

- valve

1шт.

53

NSS

NOT SOLD SEPARAT

SPRING - valve

8шт.

54

6739

SEAT

& LOCK KIT - valve

1шт.

55

NSS

NOT SOLD SEPARAT

RETAINER - valve spring

8шт.

56

NSS

NOT SOLD SEPARAT

LOCK - valve spring retaining

16шт.

57

30176

SUPPORT - rocker arm shaft

4шт.

58

195-29

WASHER,7/16"

- plain (30176 mtg.)

4шт.
